Operating Conditions; Accessories Supplied - Sony Trinitron BVM-A14F5U Operation Manual

Video signal
Differential gain
Less than 5% (for luminance from 0 to
100 cd/m
Differential phase
Less than 5° (for luminance from 0 to 100
cd/m
Frequency response
48 Hz to 30 MHz, +1 dB/ –3 dB
DC restoration Back porch type
Black level fluctuation: less than 1% for
10 % to 90% APL input signal
variation
Synchronization
Vertical blanking time
Less than 650 µs.
Horizontal blanking time
Less than 3.77 µs. (1080/60I, 1035/60I)
Picture performance
Normal scan 5% over scan of CRT effective screen
area (±10% of CRT effective screen
area)
Under scan 3% under scan of CRT effective screen
area (±10% of CRT effective screen
area)
Linearity Within a central area bounded by a circle
with a diameter equal to the picture
height, less than 0.5 % of the picture
height, and outside the same area,
about 1 % of the picture height
Color temperature
D61, D65, D93 (adjustable to other color
temperatures)
Convergence error
Within a central area bounded by a circle
with a diameter equal to the picture
height:
less than 0.4 mm with a central area
bounded by a circle and less than 0.7
mm at any other point.
Standard luminescence
100 cd/m
white signal)
Raster size stability
Less than 1% of picture height
(at 100 cd/m
to 90% APL)
Resolution 600 TV lines (16:9)
800 TV lines (4:3)
(at screen center, 100 cd/m
luminescence)
54
Specifications
2
)
2
)
2
(at standard 1 Vp-p, 100%
2
peak luminescence, 10
2

Operating conditions

Temperature 0°C to 35°C (32°F to 95°F)
Optimum temperature
20°C to 30°C (68°F to 86°F)
Humidity 0% to 90% (no condensation)
Pressure 700 hPa to 1060 hPa
Storage and transport conditions
Temperature –10°C to 40°C (14°F to 104°F)
Humidity 0% to 90%
Pressure 700 hPa to 1060 hPa

Accessories supplied

AC power cord (1)
AC plug holder (1)
Fuse (1)
Tally plate (1)
4:3 mask (1)
Operation manual (1)
Menu tree reference (1)
Cleaning of the CRT Surface (1)
Design and specifications are subject to change without
notice.
