Remote connection
1
Set the different IP address to each monitor.
2
Set the different monitor ID No. to each monitor and if
necessary, group ID No..
3
Select the connection mode by pressing the SINGLE,
GROUP or ALL button.
The lamp corresponding with the pressed button
flashes and lights after recognizing the monitor.
4
Select the monitor ID No. for the single connection
mode or group ID No. for the group connection mode
by pressing the UP/DOWN or numeric button.
Up to 99 is entered as the monitor ID or group ID No..
5
Press the ENTER qa or Ent 4 button to confirm the
setting.
The monitor ID No., group ID No. or ALL is displayed
in the display window.
After setting steps 1 to 2, follow steps 3 to 5 for the remote
connection.
Notes
• When no assigned monitor ID No. or group ID No. is
selected, setting is not changed and the previous
connection status is maintained.
• When there is same monitor ID No., the ID No. with the
lower IP address is selected.
• When the different monitor ID No. is set but the same IP
address as that of another monitor is set, the monitor
cannot be connected to the network.
• To remotely control monitors connected in the network,
the MONITOR ID, GROUP ID or IP address of monitors
should be correctly set in the NETWORK menu and
NETWORK SETTINGS menu of the SYSTEM
CONFIGURATION menu. Also, the IP address of the
monitor should be correctly set in the NETWORK
SETTINGS menu of the CONTROLLER menu.
For information about the NETWORK menu and
[D]
NETWORK SETTINGS menu, see “
System
Configuration – SYSTEM CONFIGURATION Menu” on
page 39.
For information about the NETWORK SETTINGS menu,
[H]
see “
Setting the Controller – CONTROLLER Menu”
on page 51.
Selecting the Default
Settings
BVM-A14F5M only
When you turn on the unit for the first time after purchasing
it, select the area where you intend to use this unit from
among the options. When the area is set, the color
temperature of CH1 to CH30 is set to the default value of
each area.
Color temperature
JAPAN
D93
OTHER AREA
D65
1
Turn on the power.
The SELECT SETTING screen appears.
S E L E C T S E T T I N G
J A P A N
C O L O R T E M P : D 9 3
O T H E R A R E A
C O L O R T E M P : D 6 5
2
Select the area where you intend to use the unit by
using the menu operation buttons (see page 22).
Page 21
Selecting the Default Settings
