Connection Cable Specifications for Color Temperature Probes
Special cables are required to connect color temperature
probes other than the Sony BKM-14L to the monitor.
Connection cable for UDT INSTRUMENTS SLS 9400-FC probe
Modular connector
1
Signal
N.C.
GND
RXD
TXD
GND
N.C.
Connection cable for KONICA MINOLTA CA-100 probe
D-sub 25-pin connector (male)
1
14
Signal
N.C.
TXD
RXD
RTS
CTS
N.C.
GND
N.C.
6
Pin Number
1
2
3
4
5
6
13
25
Pin Number
1
2
3
4
5
6
7
8~25
The following diagrams show specifications and pin
assignments for the required cables.
Mini DIN 8-pin connector (male)
1
2
5
8
Pin Number Signal
1
N.C.
2
N.C.
3
RTS
4
GND
5 N.C.
6
TXD
7
+5V
8 RXD
Mini DIN 8-pin connector (male)
1
2
5
8
Pin Number Signal
1
N.C.
2
N.C.
3 RTS
4
GND
5
N.C.
6 TXD
7
+5V
8
RXD
3
6
3
6
Specifications
