EWM WEGA 351 Operating Instructions Manual page 19

Item Symbol Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Item No.: 099-004934-EWM01
0
Wire feed unit
Lifting lug
Transport bar
Main switch, machine on/off
Step switch, welding voltage "coarse"
Step switch, welding voltage
Connection socket, workpiece lead
"Hard" choke tapping
Connection socket, workpiece lead
"Medium" choke tapping
Connection socket, workpiece lead
Choke tapping "soft"
Coolant tank
"Automatic cut-out of coolant pump" key button
(press to reset a triggered fuse)
Conveyor rolls, fixed castors
Conveyor rolls, guide castors
Cooling air inlet
Machine description
WEGA 351,401,451D
19
