1.2 Typical System Installation

The Voice-over-IP (VoIP) Intercom is a SIP endpoint designed to provide VoIP phone connectivity in
a tamper-proof and secure package.
Figure
of a VoIP phone system.
V3 Intercom
Speaker
Operations Guide
1-2, Figure 1-3, and Figure 1-4
Figure 1-2. Typical Installation—Door Entry/Access Control
802.3af Compliant Ethernet Switch
1 2
V3 Intercom V3 Intercom
Figure 1-3. Typical Installation—Mass Notification
Generic PoE Switch
1 2
Strobe
Loudspeaker
Light
Amplifier
illustrate how the VoIP V3 Intercoms can be installed as part
3 4 5 6
IP Phone
3 4 5 6
V3 Intercom IP Phone
930472C
IP PBX Server
IP PBX Server
