Information - Displays the information about the host. It can be IP or
◆
MAC.
Modify - To modify or delete an existing entry.
◆
To add a new entry, please follow the steps below.
Click the "Add New" button.
1.
In the Mode field, select IP Address or MAC Address.
2.
If you select IP Address, the screen in
■
In the Host Description field, create a unique description for the
●
host (e.g. Host_1).
In LAN IP Address field, enter the IP address.
●
If you select MAC Address, the screen in
■
In Host Description field, create a unique description for the host
●
(e.g. Host_1).
In MAC Address field, enter the MAC address.
●
Click the Save button to complete the settings.
3.
Click the Delete All button to delete all the entries in the table.
Click the Next button to go to the next page, or click the Previous button
return to the previous page.

Figure 80: Add or Modify an IP Host Entry

Figure 81: Add or Modify a MAC Host Entry

– 93 –
| Configuring the Router
C 4
HAPTER
Access Control
Figure 80 is displayed.
Figure 81 is displayed.
