If you change the IP Address of LAN, you must use the new IP
N :
OTE
Address to login the Router.
If the new LAN IP Address you set is not in the same subnet, the IP
N :
OTE
Address pool of the DHCP server will change accordingly at the same time,
while the Virtual Server and DMZ Host will not take effect until they are re-
configured.
Select "Network>WAN", you can configure the IP parameters of the WAN
WAN
on the screen below.
If your ISP provides the DHCP service, choose Dynamic IP, and the
1.
Router will automatically receive IP parameters from your ISP. You can
see the page as follows

Figure 35: WAN-Dynamic IP

This page displays the WAN IP parameters assigned dynamically by your
ISP, including IP address, Subnet Mask, Default Gateway, etc. Click the
Renew button to renew the IP parameters from your ISP. Click the Release
button to release the IP parameters.
MTU Size - The normal MTU (Maximum Transmission Unit) value for
◆
most Ethernet networks is 1500 Bytes. It is not recommended that you
change the default MTU Size unless required by your ISP.
C
HAPTER
(Figure 35).
– 51 –
| Configuring the Router
4
Network
