A
I TCP/IP C
NSTALL OMPONENTS
C
ONFIGURING THE
The section shows how to install and configure TCP/IP settings correctly in
Windows XP. First make sure your Ethernet Adapter is working, refer to the
adapter's manual if needed.
On the Windows taskbar, click the Start button, point to Settings, and
1.
then click Control Panel.
Click the Network and Internet Connections icon, and then click on the
2.
Network Connections tab in the following window.
Right click the icon that is shown below, then select Properties from the
3.
menu.

Figure 111: TCP/IP

In the window that is shown below, double click on "Internet Protocol
4.
(TCP/IP)."
– 118 –
PC
