Connecting The Router In Client Mode; Figure 3: Router Mode - SMC Networks SMCWBR14S-N5 Owner's Manual

2.
3.
4.
5.
6.
7.

Figure 3: Router Mode

Cable Modem
C
1.
ONNECTING THE
R C
OUTER IN LIENT
2.
M
ODE
3.
4.
5.
Locate an optimum location for the Router. The best place is usually at
the center of your network. The place must meet the Installation
Environment Requirements.
Adjust the direction of the antennas. Normally, upright is the best
direction.
Connect PCs and any switch in your LAN to the LAN Ports on the Router,
as shown in Figure 3.
Connect the DSL/Cable Modem to the WAN port on the Router, as
shown in Figure 3.
Connect the AC power adapter to the power socket on the Router, and
the other end into an electrical outlet. The Router will start to work
automatically.
Power on your PC and Cable/DSL Modem.
Power off your PC, Cable/DSL Modem, and the Router.
Locate an optimum location for the Router. The best place is usually at
the center of your network. The place must meet the Installation
Environment Requirements.
Adjust the direction of the antennas. Normally, upright is the best
direction.
Connect PCs and any switch in your LAN to the LAN Ports on the Router,
as shown in Figure 4.
Connect the AC power adapter to the power socket on the Router, and
the other end into an electrical outlet. The Router will start to work
automatically.
– 30 –
| Connecting the Router
C 2
HAPTER
Connecting the Router
Noteboook PC
