How do I configure the Router for Internet access by Ethernet users?
Sometimes the connection cannot be disconnected although you
N :
OTE
have specified a Max Idle Time, since some applications may be visiting the
Internet continually in the background.
If you are a Cable user, configure the Router following the above
N :
OTE
steps.
R I
OUTER FOR
Log in to the Router, click "Network" on the web page menu, and then
1.
click "WAN" on the submenu.
On the WAN page, select "Dynamic IP" for the WAN connection
a.
type.
Finish by clicking Save.
b.
Some ISPs require that you register the MAC Address of your adapter,
2.
which is connected to your cable/DSL Modem during installation. If
your ISP requires this, log in to the Router and click the "Network"
menu link, and then click the "MAC Clone" submenu link.
On the "MAC Clone" page, click the "Clone MAC Address" button if
a.
your PC's MAC address is a proper MAC address. Your PC's MAC
address will fill in the "WAN MAC Address" field.
Otherwise, type the MAC Address into the "WAN MAC Address" field.
The format for the MAC Address is XX-XX-XX-XX-XX-XX.
Click the Save button. Settings take effect after rebooting.
b.

Figure 117: MAC Clone
