SMC Networks WBR14S-N4 Quick Install Manual

SMCWBR14S-N4
Barricade™ N
150 Mbps 4-Port Wireless Broadband Router
Getting Started
Before you proceed to set up the SMC Barricade , connect your PC
directly to your cable/DSL modem and check if you are able to
access the Internet. If you are unable to connect to the Internet,
contact your Internet Service Provide (ISP). Once you have verified
your Internet connection, you are ready to set up your SMC
Barricade ™.
Package Contents
?
Barricade N Broadband Router (SMCWBR14S-N4) ™
?
Power Adapter
?
RJ-45 Ethernet Cable
? EZ Installation & Documentation CD
?
This Quick Installation Guide
Register Your New SMC Product!
As a registered SMC customer, you are entitled to technical
support, special product offers and educational information directly
from SMC. Please visit us on the web at
your product.
Installation Diagram
Power Adapter
SMCWBR14S-N4
E092009-AP-R02
150200000056W
™
www.smc.com to register
Cable/DSL modem
RJ-45
Ethernet Cable
Hardware Installation
Step 1
Connect your broadband modem (Cable/DSL) to the black WAN
port on the SMC Barricade using an RJ-45 Ethernet cable. ™
Step 2
Connect your PC's network card port to one of the yellow LAN
ports on the SMC Barricade using the RJ-45 Ethernet cable ™
provided.
Step 3
Unplug and then reconnect the power of the broadband modem
(Cable/DSL). Wait for the device to restart.
Step 4
Connect the included power adapter to the Barricade , and
plug the other end into an electrical outlet. Input power
requirements: 100 or 240 VAC, 50-60Hz; 5 VDC, 1A.
SMCWBR14S-N4
Power Adapter
RJ-45
Ethernet Cable
™
