10.2 Front panel buttons
The following buttons are available on the front of the unit:
Button
INPUT 1-6 Selects an audio input as the current source (if connected to a
C2 unit, these buttons have no effect and the audio source
selection is under control of the C2 unit in the 'Adjust sources'
menu)
Press and hold for 3 seconds to put the unit into Standby (power-
STANDBY
save) mode, with the LED turning red.
/ON
Press again to come out of Standby mode (button lamps will
flash once). Whilst in standby, the audio outputs will mute.
10.2.1 Multi-directional switch
The LCD is controlled from the front panel using the multi-directional switch (m/d
switch). This switch can be moved left, right, up or down and also pressed in.
These functions let the user navigate through the menu structure or change a
parameter, and are detailed in a later section.
When adjusting audio delay for instance, a single nudge and release of the m/d
switch will adjust the value by one, holding it for 1 to 3 seconds will rapidly adjust it in
single steps, and over 4 seconds will rapidly adjust in steps of 10, so that your
desired value can be quickly set.
10.3 Default settings
When your unit powers up for the first time, source 1 will be routed by default. On
subsequent power-ups the unit will default to the last source selected by the user.
®
10.4 'Windows
Control Panel' control
Your unit comes with support for control via RS-232 using the Windows
Panel which is available for download from our Internet site, and affords complete
control of the
unit.
Please refer to the 'RS232 control' section for more information.
10.5 OPTION cable control
The S2 series of switchers have been designed to be controlled by a C2-1000, C2-
2000 or C2-7000 series unit when connected via an OPTION cable provided with the
switcher.
When you connect your unit to a C2 unit via an OPTION cable, the 'Audio source'
menu on the C2 unit will expand to reflect the extra inputs available on the switcher.
Button Function
34
®
Control
