9.4
'Windows
Control Panel' control
Your unit comes with support for control via RS-232 using the Windows
Panel which is available for download from our Internet site, and provides volume
control for the
unit.
Please refer to the 'RS232 control' section for more information.
9.5 OPTION cable control
The S2 series of switchers have been designed to support control in conjunction with
C2-1000, C2-2000 or C2-7000 series units when connected via an OPTION cable
provided with the switcher.
When you connect your unit to a C2 unit via an OPTION cable, the 'Adjust Outputs'
menu will expand to show the 'Audio amp. volume' menu for adjusting the volume
from the C2 unit.
Note that unlike the other S2 units, the S2-101AA can not be
powered directly from a C2 unit via an option cable, and that a
separate 12V power supply must be used instead. Please refer to
the 'Specifications' section for more information.
9.6 Remote control
Your unit comes fitted with infra-red control capability, however infra-red controllers
are not shipped with the S2 switcher range as standard.
Please refer to the 'Infra-red remote control' section for more information.
9.7 Locking out the IR remote control
When powered up, your S2 unit will be responsive to a remote control handset by
default. The responsiveness of the S2 unit can be disabled simply by pressing
Volume+ button simultaneously with the standby button. When both buttons are
released, the panel buttons will flash twice and the unit will no longer respond to an
infra-red handset.
To re-enable responsiveness, press both buttons again, the buttons will then flash
once and the unit will again respond to handset commands.
9.8 S2-101AA extra features
Whilst the unit is in standby, the outputs will mute.
The unit has a soft start volume feature designed to remove sudden jumps to high
volume levels when the unit is switched on, causing possible damage to speakers.
32
®
