Page 1: Instruction Manual
Instruction Manual 1T-SX-632 & 1T-SX-634 HDMI V1.3 Switchers... -
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting the Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 4: Introduction
Routing Switchers, Signal Distribution Amplifiers and Cat.5 Transmission Systems. Liability Statement Every effort has been made to ensure that this product is free of errors. TV One cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. - Page 5 There are many factors affecting the quality of results when switching HDMI type signals. Some basic precautions will ensure the best possible performance from your 1T-SX-632 or 1T-SX-634 HDMI Switcher. • Output display device – The quality of the output signal will depend largely upon the type and quality of the HDMI display device used.
-
Page 6: Specifications
SPECIFICATIONS Video Inputs 1T-SX-632 2x HDMI via Type A HDMI Connector (Note 1) 1T-SX-634 4x HDMI via Type A HDMI Connector (Note 1) Video Output Both Models 1x HDSMI via Type A HDMI Connector General Frequency Bandwidth 2.25Gbps (Single Link) -
Page 7: Checking Package Contents
Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or TV One immediately. Have the Model Number, Serial Number and Invoice available for reference when you call. - Page 8 Optional Rack Mount Kit The 1T-SX-632 and 1T-SX 634 HDMI Switchers can be mounted in a standard 19” equipment rack. To mount the units, the optional RM-230 Rack Mount kit must be purchased.
-
Page 9: Operating The Unit
OPERATING the HDMI SWITCHERS The 1T-SX-632 and 1T-SX-624 HDMI Switchers can be operated via the front panel controls. If the cable run length is excessive and the quality of the display is less than optimum, you can press the Enhance switch on the front panel which will turn on a low noise amplifier within the switcher and light an LED indicating that the amplifier is in use. -
Page 10: Troubleshooting
If you experience problems using the 1T-SX-632 or 1T-SX-634 HDMI Switcher, you should attempt to determine what is wrong by attaching each of the source devices – one at a time –... -
Page 11: Limited Warranty
Should this product, in TV One’s opinion, prove defective within this warranty period, TV One, at its option, will repair or replace this product without charge. Any defective parts replaced become the property of TV One. This warranty does not apply... -
Page 12: Contact Information
CONTACT INFORMATION Should you have questions or require assistance with this product in areas not covered by this manual, please contact TV One at the appropriate location. TV One USA TV One Europe 1350 Jamike Drive Continental Approach Erlanger, KY 41018...
