Page 1: Instruction Manual
Instruction Manual MX-3141CSVA Analog Video and Audio Routing Switcher... -
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting The Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance RS-232 Protocols 10.0 Contact Information... -
Page 4: Introduction
Cat.5 Transmission Systems. Liability Statement Every effort has been made to ensure that this product is free of errors. TV One cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. It is the responsibility of the user of the hardware to check that it is suitable for his/her requirements and that it is installed correctly. -
Page 5: Specifications
SPECIFICATIONS Video Inputs MX-3141CSVA 4x CV via RCA + 4x S-Video Audio Inputs MX-3141CSVA 4x via RCA (R/L) Video Outputs MX-3141CSVA 1x CV via RCA + 1x S-Video Audio Outputs MX-3141CSVA 1x via RCA (R/L) Performance Video Bandwidth 300MHz + Video Impedance 75Ω... -
Page 6: Checking Package Contents
Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or TV One immediately. Have the Model Number, Serial Number and Invoice available for reference when you call. -
Page 7: Operating The Unit
After connecting the signal cables, the AC power adapter should be connected, first to the MX-3141CSVA and then to the AC power source. -
Page 8: Limited Warranty
Should this product, in TV One’s opinion, prove defective within this warranty period, TV One, at its option, will repair or replace this product without charge. Any defective parts replaced become the property of TV One. This warranty does not apply... -
Page 9: Rs-232 Protocols
RS-232 PROTOCOLS RS-232 Transmission Protocols: Baud Rate: 9600 bps Data Bit: 8 Bits Parity: None Stop Bit: Interconnect: MX-3141 Switcher Remote Controller Definition Definition Command Code Comment “I” + “1” Port 1 On “I” + “2” Port 2 On “I” + “3” Port 3 On “I”... -
Page 10: Contact Information
10.0 CONTACT INFORMATION Should you have questions or require assistance with this product in areas not covered by this manual, please contact TV One at the appropriate location shown below: TV One USA TV One Europe 2791 Circleport Drive Continental Approach...
