Page 1: Instruction Manual
Instruction Manual 1T-SX-632 & 1T-SX-634 HDMI V1.3 Switchers... -
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting the Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 4: Introduction
INTRODUCTION The 1T-SX-632 and 1T-SX-634 HDMI Switchers allow selection of 2 or 4 inputs respectively for display on an HDMI compliant display device. These version 1.3 HDMI switchers support all standard High Definition Television formats, PC formats from 1024x768 thru 1920x1200 and embedded HD-Audio (including Dolby® TrueHD and DTS-HD). - Page 5 There are many factors affecting the quality of results when switching HDMI type signals. Some basic precautions will ensure the best possible performance from your 1T-SX-632 or 1T-SX-634 HDMI Switcher. • Output display device – The quality of the output signal will depend largely upon the type and quality of the HDMI display device used.
-
Page 6: Specifications
SPECIFICATIONS Video Inputs 1T-SX-632 2x HDMI via Type A HDMI Connector (Note 1) 1T-SX-634 4x HDMI via Type A HDMI Connector (Note 1) Video Output Both Models 1x HDSMI via Type A HDMI Connector General Frequency Bandwidth 2.25Gbps (Single Link) -
Page 7: Checking Package Contents
CONNECTING THE HARDWARE Connect the HDMI Video Sources to the inputs of the 1T-SX-632 or 1T-SX-634 HDMI switcher, connect its output to a HDMI Compliant monitor and lastly connect the AC to DC Power Adapter. The drawings below show the locations of the inputs, output, power switch and power connector. - Page 8 Optional Rack Mount Kit The 1T-SX-632 and 1T-SX 634 HDMI Switchers can be mounted in a standard 19” equipment rack. To mount the units, the optional RM-230 Rack Mount kit must be purchased.
-
Page 9: Operating The Unit
OPERATING the HDMI SWITCHERS The 1T-SX-632 and 1T-SX-624 HDMI Switchers can be operated via the front panel controls. If the cable run length is excessive and the quality of the display is less than optimum, you can press the Enhance switch on the front panel which will turn on a low noise amplifier within the switcher and light an LED indicating that the amplifier is in use. -
Page 10: Troubleshooting
If you experience problems using the 1T-SX-632 or 1T-SX-634 HDMI Switcher, you should attempt to determine what is wrong by attaching each of the source devices – one at a time –... -
Page 11: Limited Warranty
8.0 REGULATORY COMPLIANCE The 1T-SX-632 and 1T-SX-634 HDMI Switchers have been tested for compliance with appropriate FCC and CE rules and regulations. The Power Adaptor/Supplies have been tested for compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations...
