30
VSR-4
User Manual
Alarm Recording
An alarm condition is indicated in several ways:
•
With the word ALARM, displayed on the output monitor, near the upper left hand corner of the screen.
•
With the LED Alarm Indicators on the front panel of the unit.
•
With the internal buzzer (if activated in the menu system). For information about activating the
internal buzzer during alarms, see Main Menu → Alarms on page
section of this manual.
•
By an external device, connected to the alarm output of the unit (if the unit is installed that way).
Disk Nearly Full Notification
A Disk Full. Recording has stopped message will appear on the output monitor to indicate that the unit has
stopped recording, because the disk is full and No Overwrite Mode is selected.
No Overwrite mode: The user must acknowledge the on-screen message by pressing the Enter button.
In this mode the VSR-4 will not record over previously recorded data. To continue recording, the data must be
erased (or deleted) in the Advanced / Disk Maintenance menu.
Overwrite Once mode: The user must acknowledge the on-screen message by pressing the Enter button.
The unit will continue recording again when the user presses the Record button.
Playback
Play Forward (P)
To begin normal playback, click the Play Forward button or press the P key on your keyboard. The unit will
begin playing back data from the beginning of the last recording session.
Playback is indicated:
•
As PLAY near the upper left hand corner of the output monitor, for three seconds.
Reverse Play (B)
To begin reverse playback, click the Reverse play button or press the B key on your keyboard. The unit will
begin playing back data in reverse from the end of the last recording session.
Reverse playback is indicated:
•
As REVERSE PLAY near the upper left hand corner of the output monitor, for three seconds.
If there is only one recording session on the hard disk, the unit will indicate START OF DATA on the output
monitor.
Fast Forward (Right Arrow)
During playback, click the Fast Forward button or press the right arrow key on your keyboard. The unit will
display images at a higher than normal rate. There are 4 Fast Forward rates. Repeated pressing of the Fast
Forward button will increase the playback speed.
x
of the Operator programming
