Composite Monitor Output; Svhs (Y/C) Monitor Output - GE Security VSR-4 User Manual

If an additional device is connected to the monitor's looping output, set the termination of the additional device
as 75-Ohm, and set the termination of the monitor as Hi-Z (High Impedance).
Cable
Connectors

SVHS (Y/C) Monitor Output

Connect a composite monitor capable of accepting a SVHS video signal. SVHS video output has a 4-pin mini-
DIN style connector. This style of connection is also referred to as Y/C.
75-Ohm
BNC
11
