Figure 15. VSR-4 setup as receiver and SymNet setup as sender

Streaming Settings for UDP multicast

Figure 14 illustrates streaming settings for a UDP multicast from the SymNet to the default multicast address.
The default multicast address is 230 for the first field and the balance being the unit's current IP address.
The VSR-4 is setup as a receiver in Normal mode with the Receiver Cam Map IP address set at 192.168.10.20
(The IP address of the sender) and Use default Multicast Address checked. The SymNet is setup as a sender
with the mulitcast address set at 230.168.10.20. Once these settings are saved on their respective web pages the
SymNet will begin sending multicasting video (once requested) and the VSR-4 will begin receiving streaming
video.
Figure 16. Sample UDP multicast settings
