Fast Forward is indicated:
•
As FAST FORWARD near the upper left hand corner of the output monitor, for three seconds.
Fast Reverse Play (Left Arrow)
During playback, click the Fast Reverse Play button or press the left arrow key on your keyboard. The unit
will display images (in reverse) at a higher than normal rate. There are 4 Fast Reverse Play speeds. Repeated
pressing of the Fast Reverse Play button will increase the speed.
Fast Reverse Play is indicated:
•
As REWIND near the upper left hand corner of the output monitor, for three seconds.
Pause (Pause/Break)
During playback, click the Pause button or press the pause/break key on your keyboard to pause playback,
and display a single frame on-screen.
Pause is indicated:
•
As PAUSE near the upper left hand corner of the output monitor, for three seconds.
Single Frame Advance (Up Arrow)
While in Pause mode, click the Single Frame Advance button or press the up arrow on your keyboard. The
unit will advance a single frame, then return to Pause mode.
Single Frame Rewind (Down Arrow)
While in Pause mode, click the Single Frame Rewind button or the down arrow on your keyboard. The unit
will reverse play a single frame, then return to Pause mode.
Start of Data & End of Data
If the start or end of data is reached during playback, START OF DATA or END OF DATA is indicated near the
upper left hand corner of the output monitor.
The Removable Hard Drive
Some models of the VSR-4 come with a removable hard drive. The hard drive is not hot swappable; meaning
the VSR-4 must be powered down before drive removal.
Unplug the power from the VSR-4 before removing the hard drive. The VSR-4 will not recover if the system is
CAUTION
CAUTION
not powered down during drive removal.
31
