SMART for two coupé Operator's Manual page 211

No. Accessory/Component
E
CPC, shifter, brake force booster vacuum
pump
F
Coolant pumps 1 and 2, high-voltage battery 15 A
G
®
ESP control unit
H
Exterior lamp switch, turn signal lamp
switch, cockpit switch module, on-board
diagnostics socket, exterior rear view mir-
ror heating, anti-theft warning system,
rain-light sensor, charge level and power
gauges, central locking system, instrument
cluster, Tire Pressure Monitoring System
(TPMS), brake and turn signal lamps (left and
right)
I
—
J
—
K
Safety circuit high-voltage battery
L
—
M
Rear window wiper (coupé only)
N
®
ESP control unit, EPS control unit, restraint
systems
O
Electric drive components, engine control
unit, transmission control unit, on-board
diagnostics socket, sound generator
P
Air conditioning system, exterior rear view
mirror adjustment, washer pump, audio, seat
heating, wiper switch, cruise control, soft
top switch (cabriolet only), backup lamp
Q
Auxiliary power outlet
R
Left low‑beam headlamp
S
Right low‑beam headlamp
T
—
U
Right high‑beam headlamp
V
Left high‑beam headlamp
W
Electric drive components
Fuses
Amperage Color
7.5 A Brown
Blue
25 A Neutral
10 A Red
— —
— —
15 A Blue
— —
15 A Blue
10 A Red
7.5 A Brown
10 A Red
15 A Blue
7.5 A Brown
7.5 A Brown
— —
7.5 A Brown
7.5 A Brown
7.5 A Brown
