Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 2.
Qty Reference Designator
1 U1
4 C1, C2, C3, C4
2 C5, C8
1 C6
1 C7
2 C9, C10
2 C20, C23
2 J3, J10
4 R6, R7, R8, R9
5 R1, R2, R3, R4, R5
1 J8
3 J4, J11, J12
5 J1, J2, J5, J6, J13
Description
IC, SSM2932
Capacitor, ceramic 1.0 µF, 25 V, X7R, 080
Capacitor, ceramic 1.0 µF, 25 V, X7R, 0603
Capacitor, ceramic 0.1 µF, 16 V, X7R, 0603
Capacitor, ceramic 10 µF, 16 V, X5R, 0805
Capacitor, ceramic 2.2 µF, 25 V, X5R, 0603
Capacitor, ceramic, 150 pF, 25 V, X7R, 0603
Audio jack 3.5 mm stereo SMD
Resistor, 0.0 Ω, 1/8 W, 0805
Resistor, 100 kΩ, 1/10 W, 1%, 0603
Connector, header, 2-position, 0.100" single gold
Connector, header, 3-position, 2 mm single gold
Connector, header, 2-position, 2 mm single gold
Rev. 0 | Page 7 of 8
UG-373
Supplier/Part No.
Analog Devices/SSM2932CBZ
Taiyo Yuden/TMK212B7105KG-T
Taiyo Yuden/TMK107B7105KA-T
KEMET/C0603C104J4RACTU
KEMET/C0805C106K4PACTU
Taiyo Yuden/TMK107ABJ225KA-T
AVX/06033C151KAT2A
CUI Inc./SJ-3523-SMT
Panasonic/ECG/ERJ-6GEY0R00V
Vishay/CRCW0603100KFKEA
Samtec/TSW-202
Samtec/TMM-103
Samtec/TMM-102
