- Page 1 ® NuPRO -710 Series Full Size Socket-370 All-in-one PICMG™ Bus Industrial SBC User’s Guide Recycled Paper...
- Page 3 Trademarks ® NuPRO is registered trademark of ADLINK Technology Inc. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.
- Page 5 Getting service from ADLINK ♦ Customer Satisfaction is always the most important thing for ADLINK Tech Inc. If you need any help or service, please contact us and get it. ADLINK Technology Inc. Web Site http://www.adlink.com.tw http://www.adlinktechnology.com.tw Sales & Service service@Adlink.com.tw...
-
Page 7: Table Of Contents
Table of Contents Chapter 1 Introduction..............1 FEATURES ......................1 The NUPRO-710 Package ................3 Board Layout, Jumpers and Connectors..........4 Chapter 2 Installation ..............6 Static Electricity Precautions ..............6 Installation Steps ..................7 CPU Type and BUS Clock Speed Selector ..........7 RTC Clear CMOS Memory: JP9..............9 Set DOC Memory base address...............9 Watchdog Timer setting................10 System Memory Installations ..............11... - Page 8 3.22 VGA Connector ...................24 3.23 RT1: Hardware Monitoring connector...........24 Chapter 4 BIOS Setup.............25 UPDATING NUPRO-710 BIOS (Software Flash) ........25 Standard CMOS Setup................28 BIOS Features Setup.................32 Intel 440BX Chipset Features Setup............35 4.4.1 Cache Features...................37 4.4.2 PCI and IDE Configuration..............37 Power Management Setup..............39 4.5.1 PM Timers....................40 4.5.2...
-
Page 9: Chapter 1 Introduction
Introduction This manual explains how to use this S board and INGLE BOARD OMPUTER install upgrades. It has an overview of the design and features of the board and provides useful information if you want to change the configuration of the board, or a system it is installed in. - Page 10 l IrDA Connector: Supports an infrared port module for wireless interface. l ATI Rage Pro XL Graphics Controllers (only for NUPRO-710): On-board 64-bit graphics accelerator with support for Digital Flat panel monitors and superior support for 3D and motion video, with 8MB SGRAM.
-
Page 11: The Nupro-710 Package
The NUPRO-710 Package Item Checklist Please check that your package is complete. If you discover damaged or missing items, please contact your retailer. The NUPRO-710 Single-board Computer Package comes with the following: l The NUPRO-710 Single-board Computer with built-in 2 Serial, 1 Parallel, PS/2 Keyboard, PS/2 Mouse connectors l 1 IDE ribbon cable, 1 Floppy Disk ribbon cable l one NUPRO-710 user's manual &... -
Page 12: Board Layout, Jumpers And Connectors
Board Layout, Jumpers and Connectors NUPRO-710 NUPRO-711 4 • Introduction... - Page 13 Jumpers: JP1, JP2, JP3, JP4: Bus & External Clock Selector JP5, JP6, JP7: CPU to Bus Frequency Ratio JP9: RTC Clear CMOS Memory JP8, JP10/JP11: Watchdog Timer Setting Set DiskOnChip will be mapped to Memory base JP12, JP13, JP14: address Connectors: Fan Connector: Connector for CPU cooler &...
-
Page 14: Chapter 2 Installation
Installation Several hardware settings are made through the use of jumper caps to connect jumper pins (JP) on the Single-board Computer. See¡§Map of the Single-board Computer¡¨for locations of jumpers. The jumper setting will be described numerically such as for no connection, connect pins 1 & 2, and connect pin 2 & 3 respectively. Pin 1 for our Single-board Computers is always on top or on the left when holding the Single-board Computer with the keyboard connector away from you. -
Page 15: Installation Steps
Installation Steps Before using your computer, you must follow the six steps as follows: 1. Set Jumpers on the Single-board Computer 2. Install SDRAM on board 3. Install Celeron CPU or Pentium III FC-PGA CPU into Socket 370. 4. Plug into PICMG PCI/ISA Backplane 5. - Page 16 CPU to Bus Frequency Ratio: JP1, JP2, JP3, and JP4 JP1/JP2/JP3/JP4 These jumpers set the frequency ratio between the internal frequency of the CPU and the External frequency (Called the BUS Clock) within the CPU. These must be set together with the above jumpers CPU External (BUS) Frequency Selector.
-
Page 17: Rtc Clear Cmos Memory: Jp9
RTC Clear CMOS Memory: JP9 You can use this jumper to clear the CMOS memory that stores the BIOS Setup Utility configuration record, including any passwords. After clearing the CMOS memory you must run the BIOS Setup Utility again to create and store a new configuration record. -
Page 18: Watchdog Timer Setting
Watchdog Timer setting JP8, JP10/ JP11 The Watch-Dog Timer is enabled by reading port 443H.The Watch-Dog Timer should be triggered before the Watch-Dog Timer time-out period ends, otherwise the Watch-Dog Timer as sumes the program operation is abnormal and will issue a reset signal to start again, or activate NMI (by Pull-Low IOCHK#) to the CPU. -
Page 19: System Memory Installations
System Memory Installations The NUPRO-710 supports three 128-pin DIMMs for SDRAMs or EDO DRAMs of either 8MB, 16MB, 32MB, 64MB, 128MB or 256MB to form a memory size between 8MB to 768MB. IMPORTANT: Do not mix SDRAMs or EDO DRAMs . To use Error Checking and Correction (ECC), you must used a DIMM module with 9 chips per side (e.g. - Page 20 Both ISA and PCI expansion cards may need to use IRQs. System IRQs are available to cards installed in the ISA expansion bus first, and PCI cards then use any remaining IRQs. Currently, there are two types of ISA cards. The original ISA expansion card design, now referred to as "...
-
Page 21: Chapter 3 Connectors
Connectors There are several connectors on the board for switches and indicator lights from the system case. The connectors are made of the same components as the jumper switches. There are also connectors for the on board I/O ports and the leads from a 5 -volt system power supply. IMPORTANT: Ribbon cable should always be connected with the red stripe on the Pin 1 side of the connector. -
Page 22: Ircon Connector
IRCON Connector Function + 5 V OPEN RIRRX RIRTX Connector for optional IrDA-Compliant infrared port module. IrDA Connector LCD Connector DFPCLK DFPDAT MONDET TXOM TXCM TXOP TXCP TXVSSR TXVSSR TXVSSR TXVSSR TX2M TX1M TX2P TX1P LCD Connector 14 • Connectors... -
Page 23: Usbp Connector
USBP Connector USBP Connector 0 DATA0- DATA1 DATA1 DATA0+ NC0- ATX Connector Connector for backplane ATX connector. Function 5V SB PS_ON Connectors • 15... -
Page 24: Ps-On Switch
PS-ON Switch If you use ATX power supply and have connectted a 4-pin ATX cable to backplane, the PS-ON switch will be active. A two pin cable connects to the chassis power switch. PS-ON switch The system power is controlled by a momentary switch connected to this lead. -
Page 25: Speaker Connector
Speaker Connector Connector for a system case speaker lead. Function Speaker out N.C. Ground Speaker Connector Reset Switch Connector Connector for a Reset switch lead. Reset Connectors • 17... -
Page 26: Power Led Connector
3.10 Power LED Connector Connector for a Power-On indicator LED lead. Power LED 3.11 SMI LED Connector Connector for a Suspend switch lead. SMI LED 18 • Connectors... -
Page 27: Smi Switch Connector
3.12 SMI Switch Connector Connector for a Suspend switch LED. SMI SW 3.13 IDE_LED Connector for an IDE Activity LED lead. IDE_LED Connectors • 19... -
Page 28: Internal Kb Connector
3.14 Internal KB Connector Connector for NUPRO-710 to Backplane KB Connector. KB Internqal Connector Function KB Clock KB Data Power Good 3.15 Primary, Secondary IDE Connector This connector supports the provided IDE hard disk ribbon cable. After connecting the single end to the board. Connect the two plugs at the other end to your hard disk(s). -
Page 29: Parallel Printer Connector
3.16 Parallel Printer Connector Connection for the included parallel port ribbon cable with mounting bracket. Connect the ribbon cable to this connection and mount the bracket to the case on an open slot. It will then be available for a parallel printer cable. LPT1: Parallel Printer Connector 3.17... -
Page 30: Com2 Connectors
3.18 COM2 Connectors These connectors support the provided serial port ribbon cable with mounting bracket. COM2 Connector NDCOB NSINB NSOUTB NDTRB NDSRB# NRTSB NCTSB# NRIB# 3.19 COM1 Connector (9-pin female) The COM1 connector is direct to mount on board bracket. COM1 Connector 22 •... -
Page 31: Ps/2 Mouse Connector (6-Pin Female)
3.20 PS/2 Mouse Connector (6-pin female) PS/2 Mouse will direct to IRQ12. If not detect, expansion cards can use IRQ12. PS/2 KB Connector Function Data VCC +5V 3.21 PS/2 KB Connector (6-pin female) This connection is for a standard IBM - Com patible Keyboard PS/2 KB Connector Connectors •... -
Page 32: Vga Connector
3.22 VGA Connector This VGA connection is 15-pin female for a standard Monitor. VGA Connector 3.23 RT1: Hardware Monitoring connector CPU temperature can be monitored by BIOS or Win95/98/NT4.0, utility program could be found in CD (provided by Winbond). Plug two pins connector into RT1 and V shape metal into CPU heatsink. RT1 Connector 24 •... -
Page 33: Chapter 4 Bios Setup
BIOS Setup UPDATING NUPRO-710 BIOS (Software Flash) 1. Get the AWARD BIOS Updated Diskette (Provided by ADLINK when someday BIOS need to be updated. 2. Turn OFF your computer and Boot from A: (The AWARD BIOS Updated Diskette). 3. FLASH MEMORY WRITER FILES: AWDFLASH.EXE, BIOS data code file: AWD***.ROM (*** means version of BIOS). - Page 34 ERROR Message: Do You Want To Save BIOS (Y/N). This option allows you to copy the contents of the Flash memory chip onto a diskette. This gives you a backup copy of the original NUPRO-710 BIOS in case you need to re-install it. FLASH MEMORY WRITER V5.34 Copyright (C) 1996, Award Software, Inc., For i440BX-SMC669-2A69KMHB...
- Page 35 AWARD BIOS Setup All computer mainboard of this type have a 'Setup' utility program stored in the BIOS ROM that is used to create a record of the system configuration and settings. If you are received your mainboard installed as part of a sys tem, the proper entries have probably already been made.
-
Page 36: Standard Cmos Setup
This screen provides access to the utility's various functions. Note: The 'BIOS Default' are minimized settings for troubleshooting. Use the 'Setup Defaults' to load optimized defaults for regular use. If you choose defaults at this level, modifies all applicable settings. A section at the bottom of the screen explains the controls for this screen. - Page 37 “STANDARD CMOS SETUP” displays a screen with a list of entries. Follow the on-screen instructions to move around the screen. Instructions at the bottom of the screen list the controls for this screen. Use the arrow keys to move between fields, and the <Page Up> (‘PU’), <Page Down> (‘PD’) or plus and minus keys to change the option shown in the selected field.
- Page 38 There are six categories of information you must enter “Cyls “(number of cylinders,)” Head “(number of read/write heads,)” Precomp “(write precompensation,)” LandZ “(landing zone,)” Sector (number of sectors) and “Mode”. The “Size” entry is automatically determined by the other specifications. Your hard disk vendor’s or system manufacturer’s documentation should provide you with the drive specifications.
- Page 39 Video Display Types “Video” refers to the type of video display card your system has. The options are: EGA/VGA Mono (for Hercules or MDA) CGA 40 CGA 80 You should select the setting that matches your video display card. If you have a VGA or any higher resolution card, choose the EGA/VGA setting.
-
Page 40: Bios Features Setup
BIOS Features Setup “BIOS FEATURES SETUP” is a list of system configuration options. Some entries are default required by the mainboard’s design. Others will improve your system’s performance if enabled, or let you set up some system features according to your preference. BIOS Features Setup Screen ROM PCI/ISA BIOS (2A69KMHB) BIOS FEATURES SETUP... - Page 41 happens, you can either allow the operation to continue or stop it or use anti-virus utility on a virus-free bootable floppy disk to reboot and investigate your system. Cache Control The “CPU Internal Cache” and “External Cache” default settings are “Enabled”.
- Page 42 Keyboard Interface The “Typematic Rate Setting” default setting is “Disabled”. If enabled, you can set the Typematic controls that follow. The “Typematic Rate (Char/Sec)” controls the speed at which the sys tem registers repeated keystrokes. The choices range from 6 to 30 characters per second (default is 6).
-
Page 43: Intel 440Bx Chipset Features Setup
Intel 440BX Chipset Features Setup ROM PCI/ISA BIOS (2A69KMHB) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC Auto Configuration : Enabled IN0 (V) : 1.95V IN1 (V) : 2.51V EDO DRAM Speed Selection : 60ns IN2 (V) : 3.28V IN3 (V) : 5.26V EDO CASx# MA Wait State IN4 (V) : 12.03V IN5 (V) - Page 44 EDO DRAM Speed Selection The DRAM timing is controlled by the DRAM Timing Registers. The timings programmed into this register are dependent on the system design. Slower rates may be required in certain system designs to support loose layouts or slower memory.
-
Page 45: Cache Features
4.4.1 Cache Features System BIOS Cacheable Select Enabled allows caching of the system BIOS ROM at F000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result. Enabled BIOS access cached Disabled BIOS access not cached Video BIOS Cacheable... - Page 46 Memory Hole At 15M-16M In order to improve performance, certain space in memory can be reserved for ISA cards. This memory must be mapped into the memory space below 16 MB. Enabled Memory hole supported. Disabled Memory hole not supported. Passive Release When Enabled, CPU to PCI bus accesses are allowed during passive release.
-
Page 47: Power Management Setup
Power Management Setup Power Management Setup controls the mainboard’s “green” features. The features shut down the video display and hard disk to save energy. The Power Management Setup Screen ROM PCI/ISA BIOS (2A69KMHB) POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. ACPI function : Enabled ** Reload Global Timer Events ** Power Management... -
Page 48: Pm Timers
PM Control APM When enabled, an Advanced Power Management device will be activated to enhance the Max. Power Saving is not enabled, this will be preset to No. Video Off Method This determines the manner in which the monitor is blanked. V/H SYNC+Blank This selection will cause the system to turn off the vertical and horizontal synchronization ports and writes blanks to the video... - Page 49 Suspend Mode When enabled and after the set time of system inactivity, all devices except the CPU will be shut off. HDD Power Down When enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active. Throttle Duty Cycle When the system enters Doze mode, the CPU clock runs only part of the time.
-
Page 50: Reload Global Timer Events
4.5.2 Reload Global Timer Events When Enabled, an event occurring on each device listed below restarts the global time for Standby mode. IRQ[3 -7, 9-15], NMI Primary IDE 0 Primary IDE 1 Secondary IDE 0 Secondary IDE 1 Floppy Disk Serial Port Parallel Port Intel 440BX PnP/PCI Configuration Setup... - Page 51 PNP OS Installed Select Yes if the system operating environment is Plug-and-Play aware (e.g., Windows 95). The Choice: Yes and No. Resource Controlled by The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play-compatible devices. If you select Auto, all the interrupt request (IRQ) and DMA assignment fields disappear, as the BIOS automatically assigns them.
-
Page 52: Load Bios Defaults
Used MEM Length Select a length for the m emory area specified in the previous field. This field does not appear if no base address is specified. The Choice: 8K, 16K, 32K, 64K. Load BIOS Defaults “Load BIOS SEFAULTS” loads the troubleshooting default values permanently recorded in the BIOS ROM. -
Page 53: Load Setup Defaults
Load Setup Defaults The “ LOAD SETUP DEFAULTS” option loads optimized settings from the BIOS ROM. Use this option to default settings for normal use. The Setup Default settings do not affect the Standard CMOS Setup screen. To use the Setup Defaults, Highlight the entry on the main screen and press <Enter>. -
Page 54: Integrated Peripherals
Integrated Peripherals ROM PCI/ISA BIOS (2A69KMHB) INTEGRATED PERIPHERALS AWARD SOFTWARE, INC. IDE HDD Block Mode : Enabled IR Transmittiion delay : Enabled IDE Primary Master PIO : Auto On board Parallel Port : 378/IRQ7 IDE Primary Slave PIO : Auto Parallel Port Mode : ECP + EPP IDE Secondary Master PIO... - Page 55 On-Chip Primary/Secondary PCI IDE The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately. USB Keyboard support Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have a USB keyboard. The Choice: Enabled, Disabled.
- Page 56 Parallel Port Mode Select an operating mode for the onboard parallel (printer) port. Normal EPP (Extended Parallel Port) ECP (Extended Capabilities Port) CEP +EPP PC AT parallel port Bi-directional port Fast, buffered port Fast, buffered, bi-directional port. Select Normal unless you are certain your hardware and software both support EPP or ECP mode.
-
Page 57: Setting Supervisor & User Passwords
4.10 Setting Supervisor & User Passwords The “ SUPERVISOR PASSWORD” and “ USER PASSWORD” options set passwords. The Supervisor Password is for system and Setup Utility access. The User Password is for the system only. The mainboard ships with no passwords. To create a password, highlight the type you want and press the <Enter>... -
Page 58: Ide Hdd Auto Detection
4.11 IDE HDD Auto Detection If your system has an IDE hard drive, you can use this utility to detect its parameters and enter them into the Standard CMOS Setup automatically. This utility will detect as many as four IDE drives if your system configuration supports that many. -
Page 59: Save And Exit Setup
Important!: This utility will only detect one set of parameters for an IDE hard drive. Some IDE drives can use more than one set. This is not a problem if the drive is new and there is nothing on it . If the hard disk drive is already fully formatted when you install it and different parameters than those detected here were used, you will have to enter them manually. -
Page 60: Chapter 5 Ati 3D Ragepro Xl Features
ATI 3D RagePro XL Features General Features The Rage Pro XL graphics controller is ATI first to support Desktop Digital Flat Panel Monitors. Listed below are the VGA&LCD enhanced features of NUPRO-710: l High integration results in a low cost, small footprint graphics subsystem ideal. -
Page 61: Integrated Tmds
l High quality components through built-in SCAN, Iddq, CRC and chip diagnostics. l Single chip solution in 0.25£gm, 2.5V CMOS technology, with multiple package options. l Comprehensive HDKs, SDKs and utilities augmented by full engineering support. Integrated TMDS l Integrated TMDS encoder complying to VESA Plug-and-Display (P & D) digital transmission standard. -
Page 62: Acpi Power Management
l DDC support for LCD monitors. Dedicated I/O pins are available to support DDC on LCD monitor applications. l Ratiometric Expansion in both VGA Graphics Modes and Accelerated Graphics Modes. Display modes with resolutions lower than the LCD panel resolution can be 2 tap horizontal and vertical filtering to improve both text and graphics image quality Maximum source resolution support with vertical filtering: Ÿ... -
Page 63: Floating-Point Set-Up Engine
Floating-Point Set-up Engine l The RAGE PRO XL integrates a floating-point set-up engine capable of processing up to 1.2 million triangles per second. By off-loading the set-up function form the CPU, allowing it to focus on 3D geometry and lighting transformations, the RAGE PRO XL dramatically improves the performace of the entire 3D pipeline. -
Page 64: Acceleration
2D Acceleration l Hardware acceleration of Bitblt, Line Draw, Pllygon / Rectangle Fill, Bit Masking, Monochrome Expansion, Panning/ Scrolling, Scissoring, full ROP support and h/w cursor (up to 64 x 64 x 2) l Game ccceleration including support for Microsoft's DirectDraw: Double Buffering, Virtual Sprites, Transparent Blit, Masked Blit and Context Chaining. - Page 65 Ÿ Gouraud and specular shaded polygons Ÿ Perspectively correct mip-mapped texturing with chroma-key support Ÿ Supports single pass bi- & tri-linear texture filtering, for vastly improved bi- and tri-linear performance. Ÿ Full support of Direct3D texture lighting Ÿ Texture compositing Ÿ...
-
Page 66: Motion Video Acceleration
5.11 Motion Video Acceleration l Hareware DVD decode via integrated motion compensation and IDCT circuitry for full frame rate DVD playback. l Smooth video scaling and enhanced YUV to RGB color space conversion for full-screen / full-speed video playback. l Front and back end scalers support multi -stream video for vider conferencing and other applications. -
Page 67: Software Features
5.12 Software Features l Register-compatible with VGA standards, BIOS-compatible with VESA Super VGA. l Full-featured, yet simple Windows utilities: Ÿ ATI DeskTop supports panning and scrolling across a virtual workspace Ÿ Calibration utility for WYSIWYG color l Drivers meet Microsoft's rigorous WHQL criteria and are suitable for systems which bear the "Designed for Windows ™NT and Windows™98"...
