Strong SRT 7000 User Manual

Digital high definition satellite receiver
Hide thumbs Also See for SRT 7000:
Table of Contents

Advertisement

Quick Links

Digital High Definition
Satellite Receiver SRT 7000
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRT 7000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Strong SRT 7000

Summary of Contents for Strong SRT 7000

  • Page 1 Digital High Definition Satellite Receiver SRT 7000 User Manual...

  • Page 4: Table Of Contents

    7.7 USB 8.0 TRoUblESHooTIng 9.0 SPECIfICATIonS STRong declares that this item complies with the basic requirements and other relevant regulations of directives CE 2004/108/EEC and 73/23EEC; RoHS 2002/95EEC * €0,14/Min. from German wired line * €0.42/Min. max. from mobile network Subject to alterations.

  • Page 5: Instruction

    PART 1 • English 1.0 InSTRUCTIon 1.1 Safety Instructions Do noT InSTAll YoUR RECEIvER: In a closed or poorly ventilated cabinet; directly on top of or under any other equipment; on a surface which might obstruct the ventilation slots. Do noT EXPoSE THE RECEIvER oR ITS ACCESSoRIES: To direct sunlight or any other equipment that generates heat;...

  • Page 6: Accessories

    It is advised not to store important information on USB storage devices used with the receiver. Always make backups of data on your USB storage device before using it with this receiver. STRONG will not take responsibility for any loss of information or circumstances caused by loss of information.

  • Page 7: Remote Control

    PART 1 • English 4. vIDEo (RCA) To connect to the RCA video input of your TV or VCR using an RCA cable 5. AUDIo (l/R) To connect to the audio input of your HIFI or television 6. Tv SCART To connect to TV using a SCART cable 7.

  • Page 8: Installing The Batteries

    PART 1 • English 25. u /PlAY Starts/resumes the playback. 26. 2 /PAUSE Starts/resumes timeshift when USB device is connected. Freezes/ resumes the playback of Multimedia files. 27. 3 /SToP Stops playback/timeshift/record 28. REPEAT Selects different repeat modes during playback 29.

  • Page 9: First Time Installation

    5.0 QUICk gUIDE To USIng YoUR RECEIvER We at STRONG understand that you can’t wait to enjoy your new HD receiver. The following quick guide will make you familiar with the basic operation of this device. We do, however, advice you to read the full manual to get the best performance from your STRONG HD receiver.

  • Page 10: Operation

    PART 1 • English 6.0 oPERATIon In viewing mode, several features are available to make watching TV a true pleasure. This paragraph describes these features. Please also read chapter 7.0 to get familiar with the menu of your new receiver. 6.1 Changing channels Your new receiver is equipped with different ways to change channels.

  • Page 11: Teletext

    PART 1 • English 6.4 Teletext Your receiver includes a fully featured Teletext. To access Teletext, press the TTX button in viewing mode and use the 0~9 or pq buttons to select the number of the page you wish to see. Subpages (once loaded and if available) can be selected with the tu buttons.

  • Page 12: Time Shift

    USB 2.0 HDD is connected to the receiver. Distorted picture and / or audio during Time Shift indicate a low USB device speed. STRONG cannot guarantee for USB devices used. Especially when Time Shift is activated at channels with high data rate (High quality SD/HD), STRONG cannot guarantee an accurate Playback of the Time Shift file.
  • Page 13 PART 1 • English Disable favourite Tv or radio program Repeat the step 1 described above and select Disable in the Favourite Type window. view favourite program 1. In normal viewing mode (no menu mode) press the fAvoURITE to display a list of favourite programs.

  • Page 14: Picture

    PART 1 • English 7.1.3 Sort Here you can sort your channels in the following orders: Default Sort the channels in the original order By Service Name Sort the channels in alphabetical order (A-Z) By Frequency Sort the channels in frequency order (Low-High) By Encrypt Sort the channels from free to scrambled 7.2 Picture...

  • Page 15: Channel Search

    PART 1 • English 7.3 Channel Search To access the menu press MEnU and select Channel Search. It contains two options: Installation and DB (Data Base) Management. Select an option and press ok to enter it. Press EXIT to exit the menu. 7.3.1 Installation 7.3.1.1 Satellite Selection Use pqbuttons to highlight the satellite your dish is aimed at.
  • Page 16 PART 1 • English After configuring press ok or blUE again to start scanning with the selected settings. Your receiver will now perform an automatic channel search with scan progress shown on screen. During channel search you can skip Transponders by pressing MEnU button, or quit the scan process by EXIT. Once the process is finished, all found channels will be stored and the receiver will switch to the first found channel.

  • Page 17: Time And Date Settings

    PART 1 • English 7.3.2 Db Management (save your channel settings on an USb-Storage-Device and load it anytime back) This menu allows you to up/download the channel Data Base of your receiver from/to an USB-Device. This very convenient feature enables you to save your personal settings like Channel-, Favourite-, Sat- and TP-lists on an USB Storage Device and upload them later back to the receiver.

  • Page 18: Option

    PART 1 • English 7.5 option Press MEnU and select Option. In this menu you can adjust the OSD Language, Subtitle Language, Audio Language, Digital Audio mode and Banner Time. Select an option and press tu to adjust the setting. Press EXIT to exit the menu.
  • Page 19 STRONG dealer or visit our website http://www.strong.tv for according information. In the OTA menu all necessary STRONG OTA settings (Satellite, Frequency, Symbol rate and Polarization) are already set per default but could also be changed manually. Press ok to initiate the update process.

  • Page 20: Usb

    FAT and FAT32 format. Make sure your USB device is appropriate formatted; refer to point 7.7.4 Recording Configure for more details. noTE: STRONG cannot guarantee compatibility (operation and/or bus power) with all USB mass storage devices and assumes no responsibility for any loss of data that may occur when connected to this unit.
  • Page 21 * STRONG cannot guarantee the playback of video files although extensions are listed here, as the correct playback depends on codec used, data bit rate and resolution as well. Please consult the...
  • Page 22 WARnIng: Format function will delete all records, data and information from your USB device or selected partition. STRONG will not take any responsibility for damaged or lost data on the USB device. If you have multiple partitions on your storage device, select the partition you would like to format and press ok to continue.

  • Page 23: Troubleshooting

    If the receiver does not work properly after checking it, please contact your local Serviceline or STRONG dealer. Alternatively you can send a support mail via our website: www. strong.tv. NEVER open or disassemble your receiver. This may cause a dangerous situation and will void the warranty.

  • Page 24: Specifications

    Audio playback – MP3, WMA formats Picture view – JPG, BMP formats * STRONG cannot guarantee the playback of video files although extensions are listed here, as it depends on codec used, data bit rate and resolution. Connectors SAT IN SAT OUT HDMI (V/A -Output) Type A -Version: 1.0...
  • Page 25 PART 1 • English general Data Input voltage range: 100 – 240 V AC 50/60 Hz Power consumption: max. 18 W, typ. 8.5 W (without external storage device) Power consumption in standby: max. 1 W (without external storage device) Operating temperature: 0 ~ +40 °C Storage temperature: -10 ~ +50 °C...
