TV Logic XVM-245W Operation Manual

Multi format 24-inch full hd lcd grade 1 monitor
Hide thumbs Also See for XVM-245W:

Advertisement

Table of Contents

See also: Operating Manual
Multi Format

LCD MONITOR

Operation Manual

24-Inch Full HD LCD Grade 1 Monitor
XVM-245W
MULTI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XVM-245W and is the answer not in the manual?

Questions and answers

Related Manuals for TV Logic XVM-245W

Summary of Contents for TV Logic XVM-245W

  • Page 1: Lcd Monitor

    Multi Format LCD MONITOR Operation Manual 24-Inch Full HD LCD Grade 1 Monitor XVM-245W MULTI...

  • Page 3: Table Of Contents

    Contents CAUTION FEATURES NAME & FUNCTION OF EACH PART MENU ORGANIZATION & ADJUSTMENT MENU CONTENTS OTHER FUNCTIONS PRODUCT SPECIFICATION PRODUCT LINEUP OPTIONAL ACCESSORIES FCC (Federal Communications Commission) This equipment has been tested and found to comply with the limits for class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 4: Caution

    XVM-245W Caution ALWAYS USE SET VOLTAGE. AC 100 ~ 240V (1.6A/50~60HZ), DC 24V (TYP 3.2A) [ONLY XVM-245W] All operating instructions must be read and understood before the product is operated. These safety and operating instructions must be kept in safe place for future reference.
  • Page 5 XVM-245W Caution In case the product needs replacement parts, make sure that the service person uses replacement parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.

  • Page 6: Features

    Slim and all-in-one type monitor that requires no other accessory, for optimized space utilization. Wide Screen compatible Wide Screen for easier monitoring conditions. AC/DC compatible The product may be powered by normal AC source, but also 24V DC(XVM-245W) Remote control function Remote-controlled simply with cable connection without additional peripheral equipment attached to unit.

  • Page 7: Name & Function Of Each Part

    XVM-245W Name & Function of Each Part FRONT TALLY L L MENU DOWN/BRIGHT UP/CONTRAST ENTER/VOLUME POWER CHROMA/PHASE/SCREEN SEL BLUE ONLY/MONO H/D DELAY / EXT.SYNC ANALOG MARKER MODE ASPECT UNDER SCAN [ANALOG] button/lamp - Used when ANALOG INPUT is selected. Sub Menu for analog input menu-selection appears.
  • Page 8 XVM-245W Name & Function of Each Part [H/V DELAY & EXT. SYNC] button/lamp - Used when checking horizontal sync and vertical sync simultaneously. After applying Analog sync(CLK, H, V) check whether the SYNC is corresponding with SDI, Component, Composite modes. (EXT. SYNC is available only for SDI signal currently. It will be implemented for component and composite signals soon.)
  • Page 9 XVM-245W Name & Function of Each Part REAR REMOTE RS232 RS422 IN RS422 OUT CVBS1/Y/G/S-Y CVBS2/Pb/B CVBS3/Pr/R-S-C DVI-I HDMI(HDCP) SDI-A SDI-B ETHERNET EXT.SYNC AUDIO DC 24V IN ~AC IN [REMOTE] (RJ-45) - It provides connector to build connection with extra equipment for monitor control.
  • Page 10 [Ethernet & USB] - Supports based on program download. [~ AC IN] - Used to supply AC power; 100V~240V input range. [DC 24V IN] - Used to supply DC power 24V(XVM-245W). [Information] - Input VIDEO connection method. Connector Composite Component...

  • Page 11: Menu Organization & Adjustment

    XVM-245W Menu Organization & Adjustment The product may be controlled and set system-wise through OSD displayed on the screen. 1) Menu Organization - Below is the organization of the product’s menu. 2) Menu Control - You may control various functions using MENU, UP/DOWN and ENTER buttons on the bottom front of the monitor.

  • Page 12: Menu Contents

    XVM-245W Menu Contents Below is the description of each function of the menu. [1] PICTURE PART BRIGHT This item controls the degree of brightness between MAX(50) and MIN (-50) range. CONTRAST This item controls the contrast ratio between MAX(100) and MIN(-100).
  • Page 13 XVM-245W Menu Contents SDI FORMAT This item selects input SDI format between single mode and dual mode. (Use Dual mode) SDI SAMPLING This item selects input SDI sampling mode between YCbCr and RGB. (Use Dual mode) FILTER This item selects set the filter ON for smoother transitions between colors.
  • Page 14 XVM-245W Menu Contents [2] COLOR PART COLOR TEMP - This item controls COLOR TEMPERATURE and is basically compatible with 5000K, 5600K, 6500K, 9300K and USER modes. On user mode, the user may select among R,G and B values. GAIN RED - This item controls red color.
  • Page 15 XVM-245W Menu Contents [3] MARKER PART MARKER This selects the marker type when the MARKER is displayed on the screen. MARKER may only be activated by pressing the MARKER button on the front of the monitor. Compatible MARKER types are as follows:...
  • Page 16 XVM-245W Menu Contents MARKER THICKNESS This item controls the width of marker. The degrees of width are between 1 and 7. USER MARKER H1 / H2 This item controls the marker of horizontal value. USER MARKER V1 / V2 This item controls the marker of vertical value.
  • Page 17 XVM-245W Menu Contents PASSWORD - For download, the PASSWORD set for a monitor should be match with the PASSWORD for a download program. IP ADDRESS - Type the IP Address connected to a Monitor. SUBNET MASK - Type the SUBNET MASK connected to a Monitor.
  • Page 18 XVM-245W Menu Contents [5] LAYOUT PART <PBP Mode> SCREEN SELECT - By using Chroma/Phase Hot-Key, user can select and control the individual display in Multi Mode. ALL SCREEN -> SCREEN 1 -> SCREEN 2 BORDER COLOR - This item selects the border line color between the displays in Multi Mode.
  • Page 19 XVM-245W Menu Contents WAVEFORM/VECTOR - This item set waveform and vector scope. - When set the waveform, displays the shape and form of luminance level of a signal. And Vector scope mode, displays an X-Y plot of color signal. WAVEFORM TYPE - This item sets display type of waveform(User can’t touch this item.)
  • Page 20 XVM-245W Menu Contents AUDIO VOLUME - This item controls embedded audio volume between MIN (0) and MAX (30). AUDIO CHANNEL - This item sets embedded audio channel selects CH 1 ~ CH 16 and Off. - When multi screen mode, AUDIO outputs for SCREEN 1.
  • Page 21 XVM-245W Menu Contents SOURCE ID POSITION - This item controls Source ID position. (Left-Top, Left-Bottom, Center-Top, Center-Bottom, Right-Top and Right-Bottom) TIME CODE ENABLE - This item displays the time code.(VITC, LTC) * When multi screen mode, if the same input is displayed onto 2 or more screens, TIME CODE will be only seen on the rst screen displaying the same input.

  • Page 22: Other Functions

    XVM-245W Other Functions [1] ANALOG MODE USAGE This product is capable of processing all input signals usable in ANALOG mode. The ANALOG input settings are as follows: 1. Press ANALOG button on the front of the product and activate the menu below.
  • Page 23 XVM-245W Other Functions [3] DVI SUPPORT RESOLUTION DVI-ANA mode supports the following modes: esolution e uenc 640 x 480 800 x 600 1024 x 768 720 x 400 DVI-DIG mode is separated into Graphic mode and Video mode. Graphic mode supports the below resolutions and frequencies.
  • Page 24 XVM-245W Other Functions [4] PBP MODE USAGE 1. Use PBP key to change into PBP Screen. Then the last displayed multi screen appears. In Normal Screen(when an individual screen is not selected in multi mode), key function and OSD function apply for all display simultaneously.
  • Page 25 XVM-245W Other Functions [5] INPUT LIMIT FOR ANALOG (MULTI MODE) 1. There is a limitation for Analog input in PBP Mode. (No limitation for SDI signals) 2. There are 3xBNC for the Analog inputs. So, if the BNCs or one of the BNCs are used for an Analog already, it cannot be used for another Analog input with the same BNC.

  • Page 26: Product Specification

    XVM-245W Product Specification 1 x DVI - I DVI IN 3 x BNC Analog Input Input 2 x BNC SDI A/B Channel Input 1 x HDMI HDMI Input 1 x BNC EXT SYNC INPUT 3 x BNC Analog Output Output...

  • Page 27: Product Lineup

    FOR MORE INFORMATION PLEASE VISIT : http://www.tvlogic.co.kr Developed by #914 Namsung Plaza(Ace Techno Tower 9), 345-30 Gasan-dong, Geumcheon-gu, Seoul, 153-782, KOREA Tel : +82-2-2026-1333, Fax : +82-2-2026-1339, Email: support@tvlogic.co.kr...
