NANO830/831 Intel Atom
3.1

Microprocessors

The NANO830/831 supports Intel
system to operate under Windows
microprocessor. Make sure all correct settings are arranged for your installed microprocessor
to prevent the CPU from damages.
3.2

BIOS

The NANO830/831 uses AMI Plug and Play BIOS with a single 16Mbit SPI Flash.
3.3

System Memory

The NANO830/831 supports one 204-pin DDR3 SO-DIMM socket for a maximum memory of
4GB DDR3 SDRAMs. The memory module comes in sizes of 1GB, 2GB and 4GB.
24
TM
D2550/N2600 Processor Nano-ITX Board
Hardware Description
® TM
Atom D2550/N2600 processors, which enable your
®
7 environments. The system performance depends on the
Chapter 3
Hardware Description
