- Page 1 CORDLESS HAMMER DRILL KIT 14.4V OZCD144V2A OPERATING INSTRUCTIONS w w w. o z i t o . c o m . a u To view our entire range visit...
-
Page 2: Specifications - Model No. Ozcd144V2A
SPECIFICATIONS – MODEL NO. OZCD144V2A Battery power: 14.4V Charge time: 5 – 7 hours No load speed: 0 – 350 rpm / 0 - 1100 rpm Chuck: 10mm, keyless Batteries: Gearbox: 2 Speed Hammer function: Torque rating: 18Nm Features: Adjustable torque... -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS - MODEL NO. OZCD144V2A ………. Page 1 TABLE OF CONTENTS…………………………………..Page 2 INTRODUCTION…………………………………………... Page 3 SAFETY INSTRUCTIONS………………………………..Page 3 OPERATION ……………………………………………….. Page 8 MAINTENANCE …………….…………………………….. Page 10 CONTENTS ……………………………………………….. Page 10 WARRANTY………………………………………………... Page 11... -
Page 4: Introduction
Hammer Drill. We aim to provide quality tools at an affordable price. We hope you will enjoy using this tool for many years. Your Ozito Cordless Hammer Drill OZCD144V2A has been designed to drill masonry, metal, plastic and for screw driving. It is intended for DIY use only. - Page 5 GENERAL (cont.) 5. Head protection. Always use safety glasses. Use a face or dust mask whenever the operations may produce dust or flying particles. Wear ear protection whenever the sound level seems uncomfortable. 6. Guard against electric shock. Prevent body contact with earthed or grounded surfaces (e.g.
- Page 6 GENERAL (cont.) 18. Store idle tools. When not in use, tools should be stored in a dry, locked up or high place, out of reach of children. 19. Maintain tools with care. Keep cutting tools sharp and clean for better and safer performance.
- Page 7 CHARGER AND BATTERY PACK SAFETY INSTRUCTIONS (cont.) • Do not operate charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Have it checked by an electrician or power tool repairer. • Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is required.
- Page 8 CHARGING YOUR BATTERIES This tool has been shipped in a low charge condition. You should charge it prior to use. • Plug the charger into a 240V power outlet. Connect the charger jack to the charger cradle socket. • With the battery sitting flat on a bench/table, slide the charging cradle into the recess of the battery terminals ensuring a firm connection.
-
Page 9: Operation
CHARGING YOUR BATTERIES (cont.) • All batteries gradually lose their charge. The higher the temperature the quicker they lose their charge. If you store your tool for long periods of time without using it, recharge the batteries every month or two. This practice will prolong battery life. TOOL OPERATION The ON/OFF Switch Turn the drill ON by depressing the switch. - Page 10 TOOL OPERATION (cont.) Keyless Chuck A keyless chuck has been provided with your drill to allow for easy installation and removal of bits. The chuck is divided into two parts, the rear is called the collar and the front is the body. To open and close the chuck; grasp and hold the collar of the chuck with one hand and rotate the chuck body with your other hand.
-
Page 11: Maintenance
• Blow out the ventilation slots with compressed air periodically . Note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the sander by an unauthorised person or by mishandling of the tool. CONTENTS... -
Page 12: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 3 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 36 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
