Summary of Contents for Ozito OZHD850WA
- Page 1 HAMMER DRILL 850w MODEL NO. OZHD850WA OPERATING INSTRUCTIONS w w w. o z i t o . c o m . a u To view our entire range visit...
-
Page 2: Specifications - Model No. Ozhd850Wa
SPECIFICATIONS – MODEL NO. OZHD850WA Motor Size: 850W Input: 230V ~ 50 Hz Chuck Size: 13mm (1/2”) Keyed No Load Speed: 0 – 2,800 /min Impact rate: 44, 800 bpm Net Weight: 2.5kg Drilling Capacity: Timber 25mm Steel 13mm Masonry 13mm... -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS - MODEL NO. OZHD850WA ……. Page 2 TABLE OF CONTENTS…………………………………... Page 3 INTRODUCTION…………………………………………. Page 4 SAFETY INSTRUCTIONS………………………………... Page 4 OPERATION ……………………………………………… Page 7 MAINTENANCE …………….…………………………… Page 9 CONTENTS ………………………………………………. Page 10 WARRANTY……………………………………………….. Page 11... -
Page 4: Introduction
The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. - Page 5 GENERAL SAFETY RULES Warning! Read all instructions, Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “Power Tool” in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool.
- Page 6 GENERAL SAFETY RULES (cont.) c) Avoid accidental starting. Ensure the switch is in the off position before plugging in. Carrying power tools with your finger on the switch or plugging in power tools that have the switch on invites accidents. d) Remove any adjusting key or wrench before turning the power tool on.
-
Page 7: Operation
ADDITIONAL SAFETY INSTRUCTIONS FOR HAMMER DRILLS Before drilling into walls, ceilings etc, ensure that there are no concealed power cables or pipes in the cavity. Always use the side handle. This gives you greater control if the drill accessory should become jammed. - Page 8 OPERATION (cont.) Chuck Inserting Bits Open the jaws slightly larger than the bit you are inserting. Insert the drill bit up to the flutes making sure it is centred in the jaws. Tighten the chuck by holding the rear of the chuck and rotating the front sleeve with your other hand.
-
Page 9: Maintenance
When brush wear indicator light shows red, have brushes checked/replaced by an electrician or a power tool repairer. Note: Ozito Industries will not be responsible for any damage or injuries caused by repairing of the hammer drill by an unauthorised person or by mishandling of the tool. -
Page 10: Contents
CONTENTS 1 x Hammer Drill OZHD850WA 1 x Side Handle 3 x Masonry Drill Bits 1 x Depth Rod 3 x Steel Drill Bits 1 x Kitbox 3 x Timber Drill Bits 1 x Instruction Manual OZITO INDUSTRIES PTY LTD... -
Page 11: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 3 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 36 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
