GE Profile J2S968 SERIES Technical Service Manual page 50

Oven Sensor and Lock Switch Connector (Dual Fuel Range) J2S968
MEAT PROBE*
1
50K @ RM
2
3
1
4
CONTROL
2
CONNECTOR
5
PLUG
6
7
8
OVEN TEMP SENSOR
1100 Ω @ ROOM TEMP
2650 Ω @ CLEAN TEMP
"L1"
BAKE & TIME BAKE*,
BLACK
BAKE
RELAY
L1
BK
BROIL
RELAY
L1
BR
*Approximately 25% on time in Bake.
Bake & Broil relays cannot be on at same time.
There is approx. 1 min. of dead time between
bake and broil unit operation after preheat.
Bake and broil units operate sequentially during first
(preheat)cycle.
** 1 second dead time between bake and broil
units while calling for heat in clean.
BROIL & CLEAN-UNTIL
"L1"
AFTER 750˚F IS REACHED
BLACK
BROIL
RELAY
L1
BR
UNLOCK
SW 2
THERMAL SWITCH (BAKE)
1
OPEN @169˚F
CLOSES @140˚F
THERMAL SWITCH
2
OPEN @240˚F
CLOSES @190˚F
"L2"
RED
BAKE DLB
RELAY
14.2A
2700W/16.8
BROIL
15A
3600 W / 16
"L2"
RED
BROIL
DLB
RELAY
15A
3600W/16.4
– 50 –
CONVECTION BAKE
L1 240V.
L-1
10.4A
CONV-1
CONVECTION
BAKE ELE.
2500W
CW
L1-1
CONVEC
CONVECTION ROAST
L1 240V.
L-1
15A
BROIL-1
BROIL
4000W
14.4A
CW
L1-1
CONVEC
L2
DLB
10.4A
RELAY
N
NO C
CCW DOOR
CONVECTION
SW
FAN
L2
DLB
15A
RELAY
N
NO C
CCW DOOR
CONVECTION
SW
FAN
