MTCMR‐EV2‐GP
CDMA2000
Sleep
9 volts
0.119A, 1.10W
20 volts
0.062A, 1.24W
32 volts
0.044A, 1.41W
EV‐DO
Sleep
9 volts
0.167A, 1.54W
20 volts
0.087A, 1.74W
32 volts
0.062A, 1.98W
Note: Multi‐Tech Systems, Inc. recommends that the customer incorporate a 10% buffer into their power source
when determining product load.
RF Specifications
GSM 850
Frequency RX 869 to 894 MHz 925 to 960 MHz
Frequency TX 824 to 849 MHz 880 to 915 MHz
RF Power 2W at 12.5%
Stand duty cycle
21
Typical Maximum
0.220A, 2.02W 0.560A, 5.09W
0.110A, 2.20W 0.265A, 5.30W
0.075A, 2.40W 0.175A, 5.60W
Typical Maximum
0.370A, 3.40W 0.625A, 5.68W
0.192A, 3.84W 0.345A, 6.90W
0.121A, 3.87W 0.225A, 7.20W
EGSM 900 GSM 1800
1805 to 1800
MHz
1710 to 1785
MHz
2W at 12.5% 1W at 12.5%
duty cycle duty cycle
Chapter 1—Product Description and Specifications
GSM 1900 CDMA 800
1930 to 1990 869 to 894
MHz MHz
1850 to 1910 824 to 849
MHz MHz
1W at 12.5%
duty cycle
Multi‐Tech Systems, Inc. MultiModem iCell User Guide
CDMA 1900
1930 to 1990
MHz
1850 to 1910
MHz
‐ ‐
