MTCMR­C1
Category
General
Performance
Frequency Bands
Speed
Packet Data
Circuit Switched Data
SMS
SMS
Connectors
Cellular
RS232
GPIO
Power
USB
Power Requirements
Voltage
Physical Description
Dimensions
Weight (Device Only)
Environment
Operating
Temperature*
Humidity
Certifications, Compliance, Warranty
EMC Compliance
Radio Compliance
Safety Compliance
*
UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C and has not been evaluated by UL for ambient
greater than 40° C. "UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor locations has not been evaluated by UL. UL
Certification does not apply or extend to use in vehicles or outdoor applications or in ambient above 40° C."
13
CDMA2000 1xRTT
Dual band 800/1900 MHz
Up to 153.6K bps forward and reverse
IS‐95A, IS‐95B up to 14.4K bps forward and reverse
Text and PDU
Point‐to‐Point
Cell broadcast
50 ohm SMA (female connector)
DE9
6 pin 2x3 style
2.5mm miniature (screw‐on)
Type B
9V to 32V DC
3.1 in x 4.9 in x 1.1 in
7.9 cm x 12.4 cm x 2.8 cm
0.45 lbs
200 g
‐40° to 185° F
‐40° to 85° C
Relative humidity 20% to 90% noncondensing
FCC Part 15 Class B
EN55022 Class B
FCC Part 22, 24
RSS132, 133
UL/cUL 60950‐1 2nd Ed
IEC60950‐1 2nd Ed am.1
Chapter 1—Product Description and Specifications
Description
Multi‐Tech Systems, Inc. MultiModem iCell User Guide
