MTCMR­H5
Category
General
Performance
Frequency Bands
Speed
Packet Data
SMS
SMS
Connectors
Cellular
RS232
GPIO
Power
USB
SIM Holder
Power Requirements
Voltage
Physical Description
Dimensions
Weight (Device Only)
Environment
Operating
Temperature*
Humidity
Certifications, Compliance, Warranty
EMC Compliance
Radio Compliance
Safety Compliance
Network Compliance
*
UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C and has not been evaluated by UL for ambient
greater than 40° C. "UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor locations has not been evaluated by UL. UL
Certification does not apply or extend to use in vehicles or outdoor applications or in ambient above 40° C."
15
HSPA+
Penta band 850/900/1700/1900/2100 MHz
HSDPA data service of up to 21.0 Mbps
HSUPA data service of up to 5.76 Mbps
Text and PDU
Point‐to‐Point
Cell broadcast
50 ohm SMA (female connector)
DE9
6 pin 2x3 style
2.5mm miniature (screw‐on)
Type B
Standard 1.8 and 3V SIM slot
9V to 32V DC
3.1 in x 4.9 in x 1.1 in
7.9 cm x 12.4 cm x 2.8 cm
0.45 lbs
200 g
‐22°to 158° F
‐30° to 70° C
Relative humidity 20% to 90% noncondensing
FCC Part 15 Class B
EN55022 Class B
FCC Part 22, 24
RSS132, 133
EN301 489‐1
EN489‐3 (GPS models only)
EN301 489‐7
EN301 489‐24
EN301 511
EN301 908
AS/ACIF S042.1, S042.3
UL/cUL 60950‐1 2nd Ed
IEC60950‐1 2nd Ed am.1
PTCRB
AT&T
Chapter 1—Product Description and Specifications
Description
Multi‐Tech Systems, Inc. MultiModem iCell User Guide
