RF Specifications

GSM 850
Frequency RX 869 to 894 MHz
Frequency TX 824 to 849 MHz
RF Power Stand 2W at 12.5% duty
cycle

Antenna Specifications

GSM/EGSM Antenna Requirements/Specifications

Frequency Range:
Impedance:
VSWR:
Typical Radiated Gain:
Radiation:
Polarization:
Wave:

Antennas Available from Multi-Tech Systems, Inc.

Description
Hinged Right Angle 900/1800 MHz Cellular Modem Antenna
Hinged Right Angle 800/1900 MHz Cellular Modem Antenna
Hinged Right Angle 850/900/1800/1900 MHz Cellular Modem Antenna

PTCRB Requirements Note

There cannot be any alteration to the authorized antenna system. The antenna system must be the
same type with similar in-band and out-of-ban radiation patterns and maintain the same specifications.

FCC Requirements Note

The antenna gain, including cable loss, must not exceed 3.0 dBi at 1900 MHz / 1.6 dBi at 850 MHz for
mobile operating configurations and 7.0 dBi at 1900 MHz / 2.3 dBi at 850 MHz for fixed mounted
operations, as defined in 2.1091 and 1.1307 of the rules for satisfying RF exposure compliance.

Interfaces

The wireless MultiModem has several interfaces:
●
LED function indicating operating status
●
External antenna (via SMA connector)
●
Serial and control link (via USB connector)
●
Microphone and speaker (via handset jack)
●
SIM card holder
Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide
EGSM 900
925 to 960 MHz
880 to 915 MHz
2W at 12.5% duty
cycle
824 – 960 MHz / 1710 – 1990 MHz
50 Ohms
<2.0:1
3 dBi on azimuth plane
Omni
Vertical
Half Wave Dipole
Chapter 1 – Product Description and Specifications
GSM 1800
1805 to 1800 MHz
1710 to 1785 MHz
1W at 12.5% duty
cycle
Part Number
ANF1-1HRA
ANF2-1HRA
ANQB-1HRA
GSM 1900
1930 to 1990 MHz
1850 to 1910 MHz
1W at 12.5% duty
cycle
9
