Bar Code Symbologies; Optional Features - AMT Datasouth Fastmark M4 Series User Manual

Bar code symbologies

1D bar code
Code128 subsets A.B.C,
Code128UCC, EAN128,
Interleave 2 of 5, Code 39,
Code 93, EAN-13, EAN-8,
Codabar, OSTNET, UPC-A,
UPC-E, EAN and UPC 2(5)
digits, MSI, PLESSEY,
China Post, ITF14, EAN14,
Code 11, TELPEN,
PLANET, Code 49,
Deutsche Post Identcode,
Deutsche Post Leitcode,
LOGMARS

Optional features

Product option feature
2" LCD (Liquid crystal display), 128 x 64 pixels resolution
w/white LED backlight (with 4 buttons and 2 LEDs)
WiFi 802.11 b/g/n
Zebra® CPCL emulation language support
Media sensor position
(position selectable – right/left/center position-factory
adjustment, default – center position)
Linerless kit
Mini USB cable
Mini USB to RS-232 (serial) converter cable
IP54-rated environmental case with shoulder strap (for
standard model)
IP54-rated environmental case (for linerless model)
Vehicle power adaptor
DC 7.2V/5800 mAh Li-ion rechargeable battery
Charger station 1 cell
Charger station 4 cell
Belt strap ( standard for linerless model)
Adapter for 0.75" & 1" paper core ( standard for linerless
model)
2D bar code
CODABLOCK F, mode,
DataMatrix, Maxicode, PDF-
417, Aztec, MicroPDF417,
QR, code, RSS Barcode
(GS1 Databar)
~ 59 ~
Supported Image
BITMAP, BMP, PCX, (Max.
256 colors graphics)
User Factory
option
○
○
○
○
○
○
○
○
○
○
option
○
○
○
○
○
