- Page 1 NETWORK 1275 Danner Dr Tel:330-562-7070 TECHNOLOGIES Aurora, OH 44202 Fax:330-562-1999 INCORPORATED www.nti1.com ETH-4X1 / 2X1 Manual Ethernet Switch Installation and Operation Manual MAN048 Rev Date 1/13/2005...
-
Page 2: Warranty Information
Warranty Information The warranty period on this product (parts and labor) is one (1) year from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.nti1.com information regarding repairs and/or returns. A return authorization number is required for all repairs/returns. COPYRIGHT Copyright ©... -
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Glossary..................................1 Limitations..................................1 Application Examples ..............................2 Materials ..................................3 Preparation for Installation .............................. 3 Features and Functions..............................4 Installation ..................................5 Connect the Cables ..............................5 Plug-in and Boot Up..............................6 RS232 ..................................6 Technical Specifications.............................. -
Page 4: Introduction
The NTI ETH-4X1Manual Ethernet Switch was designed to enable the connection of one of either four DEVICEs to one NETWORK or one DEVICE to one of four separate NETWORKs using standard ethernet cable. The user can control the ETH-4X1 manually to make a single connection active between one NETWORK and one DEVICE at a time. -
Page 5: Application Examples
NTI Manual Ethernet Switch APPLICATION EXAMPLES Cat 5(e) cable Straight-through RJ45 male-male NETWORK TECHNOLOGIES INCORPORATED 1275 Danner Drive Aurora, Ohio 44202 Tel: 330-562-7070 Fax: 330-562-1999 www.nti1.com ETH-4X1 Power MANUAL ETHERNET SWITCH 12VDC Cat 5(e) cable Straight-through RJ45 male-male NETWORK TECHNOLOGIES... -
Page 6: Materials
PREPARATION FOR INSTALLATION • A location should be chosen for the ETH-4X1 such that the ethernet cable from each supported device will reach it. • The ethernet cables must be run to the locations where the ETH-4X1 switch, COMMON, and the SELECTABLE(s) will be mounted. -
Page 7: Features And Functions
RS232 FEATURES AND FUNCTIONS 1. Power- LED to indicate the ETH-4X1 Manual Ethernet Switch has power to operate 2. 12VDC .5A- female connection jack for the AC adapter 3. Select Switches- (1-4)- for manual control of "COMMON" and user selectable ports (1-4) 4. -
Page 8: Installation
INSTALLATION Connect the Cables Position the ETH-4X1 Manual Ethernet Switch such that the ethernet cable from the COMMON , the AC adapter power cable, and the ethernet cables from the SELECTABLEs can reach the ETH-4X1 Manual Ethernet Switch. Connect one end of an ethernet cable to the COMMON (See Fig.1.) Connect the other end of that cable to the "COMMON"... -
Page 9: Plug-In And Boot Up
Connect the AC adapter power connector to the 12VDC port on the ETH-4X1 Manual Ethernet Switch. Make sure the power connector is properly inserted. (See Fig. 3.) Plug the AC adapter into a power outlet. The “Power” LED on the ETH-4X1 Manual Ethernet Switch should illuminate indicating that a proper power connection has been made. -
Page 10: Technical Specifications
Interconnection Cable Wiring Method The CAT5(e)UTP connection cable between the COMMON, SELECTABLE(s) and the ETH-4X1 Manual Ethernet Switch is terminated with male ethernet connectors and must be wired according to the EIA /TIA 568A industry standard. Wiring is as per the table and drawing below. -
Page 11: Troubleshooting
If an answer is not found in the chart, check the FAQs (Frequently Asked Questions) at our website at http://www.nti1.com or contact NTI directly for help at 800-742-8324 (800-RGB-TECH) in US & Canada or 330-562-7070 (worldwide). We will be happy to assist in any way we can.
