2 Features
S1D13700
X42A-G-002-01
The S5U13700B00C Rev. 1.0 evaluation board includes the following features:
• 64-pin TQFP13 S1D13700F0x Embedded Memory Graphics LCD Controller
• Headers for connecting to various Host Bus Interfaces or to the Epson PC Card
Extender
• 0.1x0.1" header with all the LCD interface signals allowing connection to a LCD panel
• On-board 32MHz crystal and option to use an oscillator instead of the crystal
• On-board +3.3V regulator
S5U13700B00C Rev. 1.0 Evaluation Board User Manual
Revision 1.0
Epson Research and Development
Vancouver Design Center
Issue Date: 2005/07/15
