Aztech WL730RT4 Quick Installation Manual

Check for Packing List
1. One Wireless BroadBand Router WL730RT4
2. One Power Adaptor
3. One Ethernet Network Cable
4. One Warranty Card
5. A Pair of Vertical Stand
6. One Set-up CD-ROM with User's Manual
7. One Quick Installation Guide
1

Application Diagram

PC with
Wireless Adaptor
CABLE/DSL MODEM
2
Connect the 802.11g
Wireless Router
Before you begin, ensure that the Wireless Router, the
1
DSL/Cable modem supplied by your IP Provider, and PC are
turned off.
WL730RT4 802.11b/g Broadband Router
6
7
Notebook with
Wireless Adaptor
WL730RT4
ARM914
PCs with Ethernet Port

Quick Installation Guide

2
Connect your DSL/Cable Modem to the Internet port on
the Wireless Router using a standard RJ-45 Ethernet
Connect an Ethernet cable to one of the
3
back of the Wireless Router to the Ethernet port on your
PC.
4
Turn on the DSL/Cable modem first.
5
Then turn on your wireless router.
6 Check the LEDs:
The ,
Power Internet
For each active LAN (PC) connection, the
LEDs (1-4) should be ON.
7
Turn on your PC.
Notes
Before setting up the Wireless Router, make sure your PCs
are configured to "Obtai n an I P (or TCP/IP ) a ddr ess
automatically".
For Windows 98 / ME / Macintosh
Please refer to the User's Guide found on the CD.
For Windows 2000 & XP
Click lick
S tar t C
Internet Connections
Connection P ro perties
Make sure the box next to
checked. Click the
the button.
Pr operties
Select
"Obtai n an I P a ddr ess automatically".
Select "
Obtain DNS server addr ess automaticlly
Then click to complete the PC configuration.
OK
Restart your computer..
3

Router Configuration

(for Internet Access)
For Windows 2000 & XP users, your computer should
8
obtain an IP Address automatically from the Wireless
Router's DHCP Server, after you've done the above steps
and restarted your computer
ports on the
LA N
, and LEDs should be ON.
WLA N
LA N A ctivit y
Cont ro l P anel Networ k a nd
(Right-clic k on) Loca l A re a
.
Internet Pr otocol (TCP/IP)
Internet Pr otocol (TCP/IP ) and
is
Click
".
