Optional Accessories

Extron Part
Rack/desk mounting kit
Captive screw audio connector
SVHS - BNC adapter
RCA-to-BNC adapter
MKP 1000
Gray
Black
White
MKP 1000M (master)
MKP 1000S (slave)

Cables

When using signals with a scanning frequency of 15-125 kHz and running distances
of 100 feet or more, use high resolution BNC cables to achieve maximum
performance. Either BNC-4 Mini HR cable or BNC-5 Mini HR cable can be used for
composite video.
Bulk cable
Extron Part
RG6 super high resolution cable
RG6-1 bulk , 500'
RG6-1 bulk , 1000'
RG6-4 bulk , 500'
RG6-5 bulk , 500'
RG6 male crimp connectors, qty. 50
BNC-2 Mini HR Cable
BNC-2 Mini HR bulk, 250'
BNC-2 Mini HR bulk, 500'
BNC-4 Mini HR Cable
BNC-4 Mini HR bulk, 500'
BNC-4 Mini HR bulk, 1000'
BNC-5 Mini HR Cable
BNC-5 Mini HR bulk, 500'
BNC-5 Mini HR bulk, 1000'
Plenum BNC-5 Mini HR Cable
Plenum BNC-5 Mini HR bulk, 500'
Plenum BNC-5 Mini HR bulk, 1000'
Assorted connectors
Extron Part
BNC connectors
BNC Mini HR crimp connectors, qty. 50
RG6 male crimp connectors, qty. 50
BNC bulkhead connectors, qty. 50
(for custom wall plates)
Matrix 50 Series Switchers • Specifications
Part #
70-077-03
10-319-10
26-353-01
10-264-01
60-239-01
60-239-02
60-239-03
60-298-01
60-298-02
Part #
22-098-02
22-098-03
22-099-02
22-100-02
100-075-51
22-123-02
22-123-03
22-032-02
22-032-03
22-020-02
22-020-03
22-103-02
22-103-03
Part #
100-074-51
100-075-51
100-076-51
A-5
