Installation, cont'd
Figure 2-5 — Captive screw connector wiring for inputs
Figure 2-6 — Phono audio connectors
5
Figure 2-7 — Captive screw connector wiring for audio output
CAUTION
RS-232/422 connection
6
2-4
Matrix 50 Series Switchers • Installation
When making connections for the Matrix 50 Series Switcher from existing
audio cables, see figure 2-6. A mono audio connector consists of the tip and
sleeve. A stereo audio connector consists of the tip, ring and sleeve. The ring,
tip, and sleeve wires are also shown on the captive screw audio connector
diagrams, figure 2-5 and figure 2-7.
Tip
Sleeve
Tip
Sleeve
Unbalanced Input
(high impedance)
Tip
Sleeve
Tip (left)
Tip (signal)
Sleeve (Gnd)
Unbalanced mono
The audio level for each input can be individually set, via the front panel or
RS-232/422, to ensure that the level on the output does not vary from input to
input. See chapter 3, Operation, chapter 4, Programmer's Guide, and chapter 5,
Matrix Software for details.
Connections for audio outputs — These 3.5 mm, 5-pole captive screw
connectors output the selected unamplified, line level audio. Connect audio
devices, such as an audio amplifier or powered speakers. See figure 2-7 to
properly wire an output connector.
Tip
See caution
Sleeve
Tip
See caution
Unbalanced Output
Connect the sleeve to ground (Gnd). Connecting the sleeve to a
negative (-) terminal will damage the audio output circuits.
By default, the audio output follows the video switch. Audio breakaway,
commanded via the front panel, under RS-232/422 control, or Windows-
based control program, allows you to select from any one of the audio input
sources. See chapter 3, Operation, chapter 4, Programmer's Guide, and
chapter 5, Matrix Software for details.
Remote/RS-232/RS-422 port — Connect a host device, such as a computer or
5
1
1
9
6
6
Female
Male
Tip
Ring
Sleeve (s)
Tip
Ring
Balanced Input
(high impedance)
Sleeve (Gnd)
Ring (right)
Tip (left)
Sleeve (Gnd)
Unbalanced stereo
Tip
Ring
Sleeve (s)
Tip
Ring
Balanced Output
touch panel control, to the Matrix 50 via
this 9-pin D connector for serial
5
RS-232/RS-422 control.
If desired, attach an MCP 1000 remote
9
control panel master unit to the
switcher's RS-232/RS-422 connector.
600 ohms
Tip
Ring
Sleeve (s)
Tip
Ring
600 ohms
Balanced Input
(600 ohms)
