Operation, cont'd

Worksheet example 1: System equipment

Figure 3-16 shows a worksheet for a 12x8 Matrix 50 switcher with audio in a
fictional organization with the system hardware annotated. Inputs 10 and 11
and output 7 have no connections in this organization, so they have been
crossed out on the worksheet.
Camera
main
podium
1
1
Main
hall
monitor
Preset #
Fill in the preset number, use colors or dashes, etc. to make connecting lines.
Indicate if the configuration is for Video, Audio, or both.
Figure 3-16 — Worksheet example 1: System equipment
Inputs include video cameras, audio tape and CD players, laser disc players,
VCRs, and a VTG 200 video test generator. Output devices include monitors,
front and rear projectors, a stereo, and a VCR. This example, labeled preset 3, is
used as the daily configuration. Choose your own method of notation.
The Extron VTG 200 video test generator connected to input 12 enables a video
test pattern to be sent to one, several, or all output devices for problem isolation
or adjustment purposes. An audio test tape or CD could be used in a similar
manner to check out the audio components.
3-16 Matrix 50 Series Switchers • Operation
Lobby
Security
Podium Audio
camera security
mic CD
camera
#2
2 3 4 5
2 3 4 5
Class Class Archive
Lobby
room #1 room #2 VCR
monitor
rear proj rear proj
Output destinations
3 Title: Daily configuration Video:
Input sources
Class Class Class Class
room #1 room #2 room #1 room #2
VCR VCR LD LD
6 7 8 9
6 7 8
Main Lunch
podium room
monitor stereo
Audio:
VTG
200
10 11 12
