C h a p t e r
Wireless POS Terminal Interface
The ICE 5700, 900 MHz wireless POS terminal interface system offers a high level of customer
convenience and reduces the time required to process a POS transaction. Because customers see the
process, they have control of the financial transaction and feel an added sense of security. The host
POS terminal and peripheral POS devices provide data encryption.

Function Blocks

The 900 MHz wireless POS terminal interface consists of the following functional blocks:
n
Terminal transceiver interface: Hypercom model FTI01 or for use with a single terminal
transceiver, a Hypercom adapter cable, P/N 810170-001.
n
Terminal transceiver: Hypercom model FXV01.
n
Customer premises wiring: If required.
n
Peripheral terminal device: This may be any Hypercom POS terminal or POS terminal
accessory such as a PIN pad or electronic receipt capture device, with a compatible optional
wireless transceiver installed. An example is an ICE 4000 POS terminal with appropriate
software installed.
4
