Configuring a Cisco 7401ASR Router
Save your settings to NVRAM. (See the
Step 4
page
mode and the setup facility, your configuration will be lost th enext time yuou load the router.
If additional Fast Ethernet interfaces are available in your system, you are prompted for their
Note
configurations as well.
Configuring Synchronous Serial Interfaces
Synchronous serial interfaces are configured to allow connection to WANs through a CSU/DSU. In the
following example, a synchronous serial interface in slot 1 is configured for a WAN connection using IP.
Follow these steps to configure synchronous serial interfaces:
Using your own addresses and mask at the setup prompts, respond to the prompts as follows:
Step 1
Configuring interface parameters:
Configuring interface serial 1/0:
Is this interface in use? [yes]:
Configure IP on this interface? [yes]:
Step 2 Determine if you are going to enable IPX on this interface; if you are, enter the unique IPX network
number:
Configure IPX on this interface? [no]: yes
Step 3 If you are using AppleTalk on the interface, enter yes. Enter yes to configure for extended AppleTalk
networks, and then enter the cable range number. Enter the zone name and any other additional zones
that are associated with your local zone:
Configure AppleTalk on this interface? [no]: yes
Extended AppleTalk network? [no]: yes
AppleTalk starting cable range [0]:
Save your settings to NVRAM. (See the
Step 4
page
mode and the setup facility, your configuration will be lost th enext time yuou load the router.
Note If additional synchronous serial interfaces are available in your system, you are prompted for their
configurations as well.
Cisco 7401ASR Installation and Configuration Guide
3-18
3-21.) If you do not save the configuration settings you created in the router using configuration
IP address for this interface: 1.1.1.30
Number of bits in subnet field [0]:
Class A network is 1.1.1.0, 0 subnet bits; mask is /24
IPX network number [2]:
3-21.) If you do not save the configuration settings you created in the router using configuration
"Saving the Running Configuration to NVRAM" section on
"Saving the Running Configuration to NVRAM" section on
Chapter 3 Starting and Configuring
OL-5419-01 B0
