Connecting I/O Cables
Table 2-4
Product
Number
GBIC-SX=
or
WS-G5484=
GBIC-LX/LH=
or
WS-G5486=
GBIC-ZX= or
WS-G5487=
For cabling specifications, including specific cable maximum distances, see
"Specifications.".
Caution If you plan to use a GBIC-LX/LH or WS-G5486 at distances greater than 984.25 feet (300 meters) over
50/125-micron or 62.5/125-micron multimode fiber, you must use the mode-conditioning patch cord to
prevent data transmission problems. (See the
page 2-21.)
Class 1 laser product.
Warning
Class 1 LED product.
Warning
Cisco 7401ASR Installation and Configuration Guide
2-18
GBIC Products, Description, and Operating Distance
GBIC
Short wavelength
(1000BASESX)
Long wavelength/
long haul
(1000BASELX/LH)
Extended distance
(1000BASEZX)
Chapter 2 Rack-Mounting, Tabletop Installation, and Cabling
Description
Contains a Class 1 laser of
850 nm for 1000BASESX
(short wavelength)
applications.
Contains a Class 1 laser of
1300 nm for
1000BASELX/LH (long
wavelength) applications.
Contains a Class 1 laser of
1550 nm for 1000BASEZX
(extended wavelength)
applications.
"Attaching the Mode-Conditioning Patch Cord" section on
Operating Distance
Operates on standard
multimode fiber-optic link
spans of up to 1804 ft
(550 m).
Operates on single-mode and
multimode fiber-optic link
spans of up to 6.2 miles
(10 km).
Operates on ordinary
single-mode fiber-optic link
spans of up to 43.5 miles
(70 km). Link spans of up to
62.1 miles (100 km) are
possible using premium
single-mode fiber or
dispersion-shifted
single-mode fiber.
Appendix A,
