Installing the Router

Attaching the Cable-Management Bracket

Figure 2-4
1
Step 1 Align the cable-management bracket to the rack-mount bracket on the left side of the Cisco 7401ASR
router.
Step 2 Using a Phillips screwdriver and the
cable-management bracket.
This completes the procedure for installing the cable-management bracket on a Cisco 7401ASR router
for a front rack-mount configuration. Go to the

Installing Rack-Mount Brackets on the Rear of the Chassis

Figure 2-5
1
To install the rack-mount and cable-management brackets on a Cisco 7401ASR router for a rear
rack-mount configuration, complete the following steps:
Locate the threaded holes in the rear sides of the chassis.
Step 1
Cisco 7401ASR Installation and Configuration Guide
2-8
Installing the Cable-Management Bracket
1
2
Cable-management bracket
Attaching the Rack-Mount Brackets to the Rear of the Chassis
ENH ANC ED
ATM
Rack-mount bracket
Chapter 2 Rack-Mounting, Tabletop Installation, and Cabling
2
M4 x 20-mm screw
screw, thread and tighten the screw to the
M4 x 20-mm
"Installing the Chassis in the Rack" section on page
2 4 screws, 8-18 x .37 in., for use with a 19-inch
rack
4 screws, 8 x .375 in., for use with a
21–23- inch rack
2-9.
2
1
OL-5419-01 B0
