Figure 1-9
Step 7 Slide the cover forward about one-half inch and then lift it from the chassis.

Removing and Installing the SDRAM DIMM

Follow these instructions to remove and replace the SDRAM DIMM:
Figure 1-10 Removing and Replacing the DIMM
1
2
Step 1 Attach an ESD-preventative wrist strap between you and an unpainted router surface.
Locate the DIMM.
Step 2
OL-5419-01 B0
Removing the Cover
EN HA NC ED
ATM
1
Spring latch on DIMM socket
DIMM
3
2
3
Notch
Cisco 7401ASR Installation and Configuration Guide
Replacing the SDRAM DIMM
1-13
