Cisco 7401ASR Installation And Configuration Manual page 29

Chapter 1 Overview and Parts Installation
Class 1 LED product.
Warning
Figure 1-6
5
1 Gigabit Interface Converter (GBIC)
2 Alignment groove
3
GBIC port 0
Use the following procedure to install a GBIC:
Step 1 Attach an ESD-preventive wrist strap between you and an unpainted chassis surface.
Step 2 Locate the label on the GBIC and turn the GBIC so the label is on top and the alignment groove is
down.
Note
Insert the GBIC into GBIC slot 0 or 1. The tabs on either side of the GBIC snap into place when you
Step 3
have completely and properly inserted the GBIC.
Repeat Step 2 and Step 3 if you are inserting a second GBIC.
Step 4
Do not remove the plug from the GBIC optical bores until you are ready to install the network interface
Note
optical fiber cable. Save the plug for future use.
This completes the GBIC installation procedure.
OL-5419-01 B0
Inserting a GBIC into the Cisco 7401ASR Gigabit Ethernet Slot 0
1
The GBIC is keyed so that it cannot be inserted incorrectly.
Installing the CompactFlash Disk, GBIC, and Port Adapter
3
2
4 GBIC port 1
5 Plug
Cisco 7401ASR Installation and Configuration Guide
4
1-9
