Isolation
1500 V
rms

3.4 Twisted Pair Data Port Specifications

Data Port
10/100 Mbps

3.5 Fiber Optical Port Specifications

For maximum flexibility RuggedCom Inc. offers a number of different transceiver choices for Gigabit fiber optical
communications. The following table details fiber optic specifications based on the order code / transceiver selected at
time of ordering.
Order Mode /
Code Connector
2LCMM MM / LC
2LC10 SM / LC
2LC25 SM / LC
NOTES:
1. Maximum segment length is greatly dependent on factors such as fiber quality, and number of patches and
splices. Please consult RuggedCom sales associates when determining maximum segment distances.
2. All cabling is duplex type unless otherwise specified.
3. All optical power numbers are listed as dBm averages.
©
2008 RuggedCom Inc. All rights reserved
Dielectric test voltage (1 minute) between coil & contacts
Media
Cat 5 UTP or STP
Tx Pwr
Tx λ λ λ λ Cable
(dBm)
(nm) Type 2
(Min/Max)
850 -9.5 / -4
50µ/125
1310 -9.5 / -3
9µ/125
1310 -5 / 0
9µ/125
Comments
Distance
100m
Rx Rx
3 Sensitivity Saturation
(dBm) 3 (dBm)
-20
-22
-22
21
Connector Type
RJ45 or M12
Typical
Distance 1
3 (km)
0 0.5
-3 10
-3 25
Rev104
Power
Budget
(dB)
13
18.5
19.5
