The printer should advance the ticket just beyond the edge of the cabinet. The position
of the tear can be controlled by changing the cut count setting in the OPERATOR
MENU (see Appendix A). If you are not able get the desired tear position, then make
sure your ticket stock was manufactured to proper specifications.
Once a year the optos eyes should be blown off with air.
Ticket Load
Circuit board
Black Aluminum
Bracket
5
/
"
64
Allen Head
Screws
Wht/Red/Blk
Wires
10
FEED DIRECTION
Opto Eyes
TO LOGIC
BOARD
Ticket Cut/ Tear
Circuit board
Paper Guide
Allen Head
Screws
On some models these
connectors plug into the
back of the circuit board
Grn/Red/Blk
Wires
Figure 8 - Optical Devices
5
/
"
64
