DIGI-HDMI-4X2 RS232 Codes
Misc. Commands
Function
Get Device Type
Get Device Status
Output 1 Commands
Function
Toggle Input 1
Toggle Input 2
Toggle Input 3
Toggle Input 4
Toggle Input Forward
Toggle Input Backward
Output 2 Commands
Function
Toggle Input 1
Toggle Input 2
Toggle Input 3
Toggle Input 4
Toggle Input Forward
Toggle Input Backward
*Note: the space between "cir" and the code is required.
www.intelix.com
Code Return String
br <space> ASCII string containing the
letter "a" followed by the
name of the device
bc <space> ASCII string in the format of:
"\r\n" + "s1Ys2Ys3Ys4Y" +
"\r\n" where Y is the input
source being routed to each
output. The value of Y maps
as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
The outputs channels map as
follows:
s1 = output 1
s2 = output 2
s3 = output 3
s4 = output 4
Code Return
cir 17\r The updated status for output
1. Represented as an ASCII
cir 12\r
string in the format of "sXY"
cir 59\r
where:
cir 08\r
• X is a one based output
cir 11\r
channel
cir 1B\r
• The value of Y maps as
follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
Code Return
cir 5E\r The updated status for output
cir 06\r 2. Represented as an ASCII
string in the format of "sXY"
cir 05\r
where:
cir 03\r
• X is a one based output
cir 48\r
channel
cir 55\r
• The value of Y maps as
follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
