I
NSTALLATION
The Acrobat can be permanently installed or hung with a clamp (not included), or
it can be placed on the floor as described below. For maximum lamp life, do not
place the fixture directly on or beside a speaker cabinet or other source of strong
vibrations.
Once the Acrobat is installed and connected, the focus may be adjusted by
loosening and sliding the focus adjustment knob.
Warning!
Block access below the work area before proceeding.
Warning!
Always use a secure means of secondary attachment.
To inst all the mount ing bracket
Install the mounting bracket on the chassis as shown. Place the washers on
the stud before the bracket.
To inst all or hang the Acrobat
1 Verify that the structure can support at least 10 times the weight of all
installed fixtures, clamps, cables, auxiliary equipment, etc.
2 If hanging the fixture with a rigging clamp, verify that the clamp is
undamaged and is designed for the fixture's weight. Bolt the clamp securely
to the bracket with a grade 8.8 (minimum) M12 bolt and lock nut, or as
Acrobat user manual

Installation

4
7
